NEEWER RF1-N TTL Macro Ring Flash Light User Manual

1. Entwodiksyon

The NEEWER RF1-N TTL Macro Ring Flash Light is designed for macro photography, providing even illumination and minimizing harsh shadows. It is compatible with various Nikon cameras and offers multiple flash modes and advanced functions to enhance your photographic capabilities.

Image 1.1: The NEEWER RF1-N Macro Ring Flash provides soft, even illumination, effectively eliminating harsh shadows in macro photography. It features a GN15 guide number, 76Ws flash power, and an ultra-lightweight design at 13oz/368g.

2. Pake kontni

Verifye ke tout atik ki nan lis anba a yo enkli nan pakè ou a:

• 1 x RF1-N Ring Flash Light
• 1 x manyèl itilizatè
• 1 x netwayaj twal
• 8 x Color Filters (White, Red, Green, Yellow)
• 8 x Bag Adaptè Lantiy (49mm, 52mm, 55mm, 58mm, 62mm, 67mm, 72mm, 77mm)

Image 2.1: The package includes the RF1-N Ring Flash Light, a user manual, a cleaning cloth, four color filters (white, red, green, yellow), and eight lens adapter rings for various filter thread sizes.

3. Enstalasyon

3.1 Mete flach la sou kamera ou a

1. Slide the flash unit onto your camera's hot shoe until it locks into place.
2. Secure the flash by tightening the locking mechanism on the hot shoe mount.

3.2 Installing Lens Adapter Rings

1. Determine the filter thread size of your camera lens.
2. Select the appropriate adapter ring from the provided set (49mm, 52mm, 55mm, 58mm, 62mm, 67mm, 72mm, 77mm).
3. Screw the adapter ring onto the front filter thread of your camera lens.
4. Attach the ring flash head to the installed adapter ring.

3.3 Enstalasyon batri

The RF1-N requires 4x AA batteries. For optimal performance, use 1.5V high-drain rechargeable or alkaline batteries.

1. Louvri kouvèti konpatiman batri a sou inite flash la.
2. Mete 4 pil AA, asire polarite kòrèk (+/-).
3. Fèmen kouvèti lòj batri a byen.

Image 3.1: The RF1-N Macro Ring Flash is shown mounted on a Nikon camera, demonstrating its compact and integrated setup for macro photography.

4. Operasyon Modes

The RF1-N offers three primary flash modes to suit various photographic needs:

4.1 TTL Mode (Through-The-Lens)

In TTL mode, the flash automatically determines the correct exposure by measuring the light reflected from the subject through the camera's lens. This mode is ideal for quick and accurate exposure in changing light conditions.

4.2 M Mode (Manual)

Manual mode allows you to set the flash output power manually from 1/1 (full power) to 1/128. This provides precise control over lighting for consistent results, especially in studio or controlled environments.

4.3 MULTI Mode (Stroboscopic)

MULTI mode enables stroboscopic flashes, firing multiple times during a single exposure. This is useful for capturing a series of movements in one frame.

4.4 Independent Flash Tubes and Ratio Control

The A/B flash tubes can be controlled independently or collectively. In TTL/M modes, the flash ratio is adjustable from 8:1 to 1:1 to 1:8 in 1/2 stop increments, allowing fine-tuning of image contrast and directional lighting.

Image 4.1: The flash supports M Manual Mode for power adjustment (1/1-1/128), Strobe Mode for capturing motion, and Front/Rear Curtain Sync for creative effects.

Image 4.2: The RF1-N allows independent control of its A/B flash tubes, offering Full Flash, AB Flash Ratio, Left Flash, and Right Flash modes for versatile macro lighting.

5. Fonksyon avanse

The RF1-N incorporates several advanced functions for precise exposure control:

• Exposure Compensation (FEC): Ajiste pwodiksyon flach la pou ajiste ekspozisyon an avèk presizyon.
• Exposure Bracketing (FEB): Automatically takes multiple shots at different flash exposures.
• Flash Lock (FEL): Locks the flash exposure for a specific area of the scene.
• Senkronizasyon rido devan/dèyè: Allows synchronization with either the beginning or end of the shutter exposure for creative motion blur effects.
• Pak senkronizasyon PC: Provides a wired connection for flash synchronization.

Image 5.1: The flash supports automatic metering with features like Flash Exposure Compensation (FEC), Flash Bracketing (FEB), and Flash Exposure Lock (FEL) for precise lighting control.

6. Pwovizyon pou pouvwa

The RF1-N is powered by 4x AA batteries. It also supports an external CP-E4 battery pack for extended use.

• Dire Flash: 1/400s - 1/19300s
• Tan resiklaj: 0.1s - 2.7s
• Kantite flash: 100 - 1500 (depending on battery type and output power)

Image 6.1: The flash offers convenient power supply, providing approximately 1/400s-1/19300s flash duration, 100-1500 flashes, and 0.1-2.7s recycling time, powered by four AA batteries or a CP-E4 external battery pack.

7. Assist Focus Lights & LCD Screen

7.1 Assist Focus Lights

Two 0.59W assist focus lights are integrated into the ring flash, offering 10 brightness levels. These lights aid in achieving focus in dim lighting conditions.

7.2 LCD Screen and Custom Functions

The concise LCD screen provides a clear user interface for easy reference and adjustment of settings. Customizable functions include:

• Dòmi Otomatik (STBY): Vire sou / Off
• Buzzer (BEEP): Turn On/Off, or turn off after 12 seconds
• Backlight Illumination Time (LIGHT): On/Off, or Always On
• LCD Contrast (LCD): 7 levels (-3 to +3)

Image 7.1: The RF1-N features dual modeling lights for improved focusing in dark environments and a clear LCD screen for accessing 4 custom function settings, including auto sleep, buzzer, backlight duration, and LCD contrast.

8. Color Gels & Adapter Rings

8.1 Color Gel Filters

Four color gel filters (white, red, green, and yellow) are included to help create atmospheric and artistic lighting effects in your macro photography.

8.2 Lens Adapter Rings

Eight adapter rings are provided to ensure compatibility with a wide range of camera lenses with filter threads of 49mm, 52mm, 55mm, 58mm, 62mm, 67mm, 72mm, and 77mm.

Image 8.1: The RF1-N includes four color gel filters (white, red, green, orange) that can be easily inserted to modify the light output and create various artistic effects for macro shots.

9. Konpatibilite

The NEEWER RF1-N TTL Macro Ring Flash Light is compatible with the following Nikon camera models:

• Nikon Z9, Z8, Zfc, Z50, Z30, Z5, Z6, Z7, Z6II, Z7II
• Nikon D4, D5, D6, D60, D70S, D90, D100, D200, D300, D610, D700, D750, D780, D800, D850
• Nikon D3100, D3200, D3300, D3400, D3500, D5000, D5100, D5200, D5300, D7100, D7500

Nòt: Pa konpatib ak Nikon D810.

Image 9.1: The RF1-N is compatible with a wide range of Nikon Z and D series cameras, and includes lens adapters for 49/52/55/58/62/67/72/77mm filter threads.

10. Antretyen

Proper maintenance ensures the longevity and optimal performance of your RF1-N Macro Ring Flash Light.

• Netwayaj: Sèvi ak yon twal mou epi sèk pou netwaye flach la. Pou pousyè tè ki difisil pou retire, yon ti kras twal sèk.amp Ou ka itilize yon twal, epi seche l touswit apre. Pa sèvi ak pwodui chimik ki agresif oswa pwodui netwayaj abrazif.
• Lens Adapters and Gels: Keep adapter rings and color gels clean and free of dust. Use the provided cleaning cloth for lenses and optical surfaces.
• Depo: When not in use, store the flash in a dry, cool place, away from direct sunlight and extreme temperatures. Remove batteries if the unit will not be used for an extended period to prevent leakage.
• Manyen: Evite lage flach la oswa soumèt li a gwo enpak, paske sa ka domaje konpozan entèn yo.

NAN. Depanaj

If you encounter issues with your RF1-N Macro Ring Flash Light, refer to the following common troubleshooting steps:

• Flash la pa ap tire:
  • Tcheke si flach la byen monte sou soulye cho kamera a.
  • Asire w ke pil yo byen enstale epi yo gen ase chaj. Ranplase yo si sa nesesè.
  • Verify that the flash is turned on and not in sleep mode.
  • Tcheke paramèt kamera a pou asire w ke flach ekstèn lan aktive.
• Ekspozisyon ki pa kòrèk:
  • In TTL mode, ensure your camera's metering mode is appropriate for the scene.
  • In M mode, adjust the flash output power manually.
  • Check for any active Exposure Compensation (FEC) settings on the flash or camera.
• Ekran LCD pa parèt:
  • Ensure the flash is powered on.
  • Tcheke nivo batri yo.
  • Adjust LCD contrast settings if the display is faint.
• Ring Flash Not Attaching to Lens:
  • Ensure you are using the correct size adapter ring for your lens filter thread.
  • Check for any debris or damage on the adapter ring or lens thread.

If problems persist, consult the NEEWER support websit oswa kontakte sèvis kliyan.

12. Espesifikasyon

Image 12.1: Detailed specifications for the NEEWER RF1-N Macro Ring Flash, including guide number, power, color temperature, compatibility, and dimensions.

13. Garanti ak sipò

Pou enfòmasyon sou garanti a ak sipò kliyan, tanpri al gade paj ofisyèl NEEWER la. websit la oubyen kontakte machann ou an. Kenbe resi acha ou kòm prèv acha pou nenpòt reklamasyon garanti.

NEEWER Ofisyèl Websit: www.neewer.com
