Manyèl Itilizatè Kas Bluetooth pou Kas Motosiklèt EJEAS E1

1. Entwodiksyon

The EJEAS E1 is a Bluetooth headset designed for motorcycle helmets, providing communication and entertainment for single riders. It features Bluetooth 5.3 technology for stable connections, DSP&CVC noise reduction for clear audio, and an IP65 waterproof rating for various weather conditions. This manual provides detailed instructions for installation, operation, and maintenance of your EJEAS E1 headset.

Image 1: EJEAS E1 Motorcycle Helmet Bluetooth Headset main unit.

2. Pake kontni

Tanpri verifye ke tout atik ki nan lis anba a yo enkli nan pakè ou a:

• 1x E1 Motorcycle Bluetooth Headset Unit
• 1x Ear Speaker and Microphone Set
• 1x Accessory Post and Accessory Clip
• 1x Kalite-C Chaje Kab
• 1x manyèl itilizatè
• 4x kousinen adezif

Image 2: Contents of the EJEAS E1 package, including the headset, speakers, microphone, mounting clips, charging cable, and user manual.

3. Pwodwi souview

The EJEAS E1 headset integrates several features for an enhanced riding experience:

• Bluetooth 5.3: Provides faster data transmission and a more stable connection.
• DSP&CVC Noise Reduction: Reduces echo and ambient noise for clearer communication.
• 750mAh batri: Offers up to 60 hours of working time and 360 hours of standby time.
• IP65 ki enpèmeyab: Ensures reliable performance in rain and other outdoor conditions.
• Radyo FM: Built-in function with a frequency range of 60-108 MHz.
• Asistan vwa: Supports activation of your mobile phone's voice assistant.

Image 3: Illustration of the advanced Bluetooth 5.3 chip for faster and more stable connections.

Image 4: Visual representation of DSP&CVC noise reduction technology for clear audio.

Image 5: Depiction of the IP65 waterproof and dustproof capabilities, suitable for various outdoor conditions.

4. Enstalasyon

Follow these steps to install the EJEAS E1 headset on your helmet:

1. Atache klip montaj la: Insert the back clip into the edge of your helmet. Ensure it is securely fastened.
2. Mount the E1 Unit: Slide the E1 main unit onto the clip slot until it clicks into place.
3. Enstale Oratè yo ak Mikwofòn nan: Use the provided Velcro pads to stick the speakers and boom microphone inside your helmet, positioning them near your ears and mouth for optimal audio.
4. Connect Speakers/Mic: Plug the speaker and microphone cable into the Type-C earphone interface on the E1 main unit.

Image 6: Step-by-step guide for installing the EJEAS E1 headset components onto a motorcycle helmet.

5. Enstalasyon

5.1 Chaje Aparèy la

Before first use, fully charge the E1 headset. Connect the provided Type-C charging cable to the charging port on the unit and a USB power source. The red indicator light will be on during charging and will turn off once fully charged. Charging time is approximately 2 hours.

Image 7: The EJEAS E1 headset connected to a USB-C charging cable, illustrating the charging process and battery life indicators.

5.2 Bluetooth Pairing

To connect your E1 headset to a mobile phone:

1. Ensure the E1 headset is powered off.
2. Press and hold the Power button until the indicator light flashes blue and red alternately, indicating pairing mode.
3. On your mobile phone, go to Bluetooth settings and search for available devices.
4. Select "EJEAS E1" from the list. Once connected, the indicator light will flash blue slowly.

Image 8: The EJEAS E1 headset wirelessly connecting to a mobile phone via Bluetooth 5.3.

6. Operasyon Enstriksyon

Familyarize w avèk bouton yo ak fonksyon yo:

Image 9: Detailed diagram of the EJEAS E1 headset's buttons and interfaces.

• Limen/Etenyen: Peze epi kenbe bouton Pouvwa a pou 3 segonn.
• Kontwòl Volim: Press the 'Vol +' button to increase volume, 'Vol -' button to decrease volume.
• Lektur Mizik:
  • Press the Phone button once to Play/Pause music.
  • Press 'Vol +' for 2 seconds for the next track.
  • Press 'Vol -' for 2 seconds for the previous track.
• Apèl nan telefòn:
  • Press the Phone button once to Answer/End a call.
  • Press the Phone button for 2 seconds to Reject a call.
  • Double-press the Phone button to Redial the last number.
• Asistan vwa: Press the Voice Assistant button once to activate your phone's voice assistant (e.g., Siri, Google Assistant).
• Radyo FM:
  • Press the FM Radio button once to turn on/off the FM radio.
  • When FM is on, press 'Vol +' or 'Vol -' for 2 seconds to scan for the next/previous station.

7. Antretyen

To ensure the longevity and optimal performance of your EJEAS E1 headset:

• Netwayaj: Sèvi ak yon mou, damp cloth to clean the headset unit. Avoid using harsh chemicals or abrasive cleaners.
• Depo: Sere aparèy la nan yon kote ki fre epi sèk lè w pa ap itilize li. Evite tanperati ekstrèm.
• Swen batri: For extended storage, charge the battery to approximately 50% every three months to prevent deep discharge.
• Ekspozisyon dlo: While IP65 waterproof, avoid submerging the device in water. Ensure the Type-C port cover is securely closed during wet conditions.

NAN. Depanaj

If you encounter issues with your EJEAS E1 headset, refer to the following common problems and solutions:

• Pa gen pouvwa: Ensure the battery is charged. Connect the charger and check if the red indicator light appears.
• Pa ka konekte ak telefòn nan:
  • Ensure the headset is in pairing mode (alternating blue and red light).
  • Etenn epi aktive Bluetooth telefòn ou an.
  • Try restarting both the headset and your phone.
• Pa gen son/Volim fèb:
  • Check the volume level on both the headset and your phone.
  • Ensure the speakers are correctly plugged into the headset unit.
  • Verify that the speakers are positioned correctly inside the helmet, close to your ears.
• Mikwofòn pa travay: Ensure the microphone is correctly plugged in and positioned near your mouth.
• Koneksyon tanzantan: Ensure there are no significant obstructions between the headset and your phone. Keep the phone within the effective Bluetooth range.

9. Espesifikasyon

10. Garanti ak sipò

EJEAS products are designed for reliability and performance. For warranty information or technical support, please refer to the contact details provided with your purchase documentation or visit the official EJEAS websit la. Tanpri konsève prèv acha ou a pou reklamasyon garanti.
