1. Entwodiksyon
This user manual provides comprehensive instructions for the safe and efficient operation, maintenance, and troubleshooting of your YDBMY Commercial Desktop Snowflake Ice Machine. Please read this manual thoroughly before operating the machine to ensure proper usage and to prevent damage or injury.
The YDBMY Commercial Desktop Snowflake Ice Machine is designed for commercial use in various settings such as restaurants, cafes, beverage shops, and bars. It produces high-quality snowflake ice, also known as shaved ice or bingsu, with adjustable thickness settings.
Figure 1: YDBMY Commercial Desktop Snowflake Ice Machine. This image displays the main unit of the ice machine, featuring a top-mounted water bottle for supply and two examples of delicious shaved ice desserts that can be created.
2. Pwodwi souview ak Karakteristik
The YDBMY Commercial Desktop Snowflake Ice Machine is a robust and efficient appliance built for continuous ice production. Its design emphasizes durability, ease of use, and hygiene.
Karakteristik kle:
- Three-in-one Snowflake Ice Maker: Capable of producing ice in three states: noodles, flakes, and snowflakes.
- Reglabl vitès: Features a speed adjustment button to control the production rate and ice consistency.
- Segondè efikasite: Equipped with a 750W imported energy-saving compressor for powerful and rapid ice production, up to 120 kg of pure water ice daily.
- Konstriksyon dirab: Entire body made of food-grade 304 stainless steel, ensuring rust-free operation, beauty, and ease of cleaning.
- Operasyon fasil: One-button control for starting and stopping the machine.
- Refwadisman efikas: Integrated cooling fans for efficient heat dissipation and stable performance.
Figure 2: Machine Features. This image illustrates key design elements including the thick 304 stainless steel body, the simple one-button operation panel with speed adjustment, and the effective cooling fans.
Figure 3: Labeled Components. This diagram points out the main parts of the ice machine, including the water barrel, internal roller, control switches, ice blade, and cooling fans, providing a clear understanding of its structure.
3. Espesifikasyon
Detailed technical specifications for the YDBMY Commercial Desktop Snowflake Ice Machine:
| Atribi | Valè |
|---|---|
| Non pwodwi | Air-cooled Ice Machine |
| Modèl | B0F6JJ9PSP |
| Voltage | 110V/220V 50/60Hz (Please check your local voltage kondisyon) |
| Pouvwa | 750W |
| Dimansyon pwodwi (L x W x H) | 57cm x 31cm x 42cm (22.4 x 12.2 x 16.5 pous) |
| Pwa nèt | 23kg (50.7 liv) |
| Maximum Ice Production | 120 kg (264 lbs) of pure water ice per 24 hours |
| Materyèl | Asye pur 304 ki apwopriye pou manje |
| Pwodwi pou Telefòn enkli | 2 x Ice Buckets |
Figure 4: Product Specifications Diagram. This image provides a visual representation of the machine's dimensions, power, net weight, and daily ice production capacity.
4. Enstalasyon
4.1 Debake
- Carefully remove the ice machine from its packaging.
- Inspect the machine for any signs of damage during transit. If damage is found, do not operate and contact customer support immediately.
- Retire tout materyèl anbalaj yo, tankou nenpòt fim pwoteksyon oswa tep.
- Verify that all accessories, including the two ice buckets, are present.
4.2 Plasman
- Place the ice machine on a stable, level surface capable of supporting its weight when full.
- Ensure adequate ventilation around the machine. Maintain at least 10 cm (4 inches) of clearance on all sides, especially around the cooling fans, to allow for proper airflow and heat dissipation.
- Avoid placing the machine in direct sunlight or near heat sources (e.g., ovens, radiators) as this can affect ice production efficiency.
- The machine is designed for indoor use only. Do not expose it to rain or excessive moisture.
4.3 Koneksyon pouvwa
- Before plugging in, ensure the machine's voltage (110V/220V) matches your local power supply.
- Connect the power cord securely to a grounded electrical outlet. Do not use extension cords or adapters.
4.4 Pwovizyon dlo
- This machine uses a top-mounted water bottle for water supply. Ensure the water bottle is filled with pure water.
- Carefully place the filled water bottle onto the designated water inlet on top of the machine. Ensure it is seated correctly to allow water to flow into the reservoir.
4.5 Netwayaj Premye
- Before first use, it is recommended to clean the internal components that come into contact with water and ice.
- Siye deyò asye pur la ak piblisiteamp twal.
- Run a cycle with clean water and discard the first batch of ice to flush out any manufacturing residues.
5. Operasyon Enstriksyon
5.1 Limen/Etenyen
- To power on the machine, locate the main power switch (refer to Figure 3 for location) and toggle it to the 'ON' position.
- To power off, toggle the main power switch to the 'OFF' position.
5.2 Pwodiksyon glas
- Ensure the water bottle is properly installed and contains sufficient pure water.
- Limen switch prensipal la.
- Press the 'Start' button (often combined with the power switch or a separate button, refer to Figure 2 for "One button open and stop"). The machine will begin the ice-making process.
- Place an ice bucket or suitable container beneath the ice dispensing chute.
- The machine will automatically dispense snowflake ice.
Figure 5: Ice Dispensing. This image demonstrates the machine's rapid and continuous ice dispensing capability, showing snowflake ice falling into a serving bowl.
5.3 Adjusting Ice Thickness/Type
- The machine features a speed control switch (refer to Figure 3) that allows you to adjust the consistency of the ice produced.
- Rotate the speed control knob to achieve different ice states: noodles, flakes, or snowflakes. Experiment with the settings to find the desired texture for your applications.
- Adjustments can typically be made while the machine is operating.
Figure 6: Applications of Snowflake Ice. This image showcases a variety of desserts and beverages that can be made using the snowflake ice produced by the machine, demonstrating its versatility.
6. Antretyen
Regular cleaning and maintenance are crucial for ensuring the longevity, hygiene, and optimal performance of your ice machine.
6.1 Netwayaj chak jou
- After each day's use, turn off and unplug the machine.
- Wipe down the exterior stainless steel surfaces with a soft, damp twal ak detèjan twò grav. Seche byen.
- Clean the ice dispensing chute and any removable parts that come into contact with ice or water. Rinse with clean water and air dry.
- Empty and clean the ice buckets provided.
6.2 Weekly Cleaning (or as needed)
- Eleman Entèn: For thorough cleaning, it may be necessary to access internal components. Refer to the machine's design for removable parts like the ice blade or roller cover. Clean these parts with food-grade sanitizer or a solution of mild detergent and water. Rinse thoroughly.
- Rezèv dlo: If accessible, drain and clean the water reservoir to prevent mineral buildup and bacterial growth.
- Fanatik refwadisman: Periodically inspect the cooling fans (refer to Figure 3) for dust and debris accumulation. Use a soft brush or vacuum cleaner to gently remove any buildup, ensuring proper airflow.
6.3 Descaling (Monthly or Bi-Monthly, depending on water hardness)
- Mineral deposits from water can accumulate over time, affecting ice quality and machine efficiency.
- Use a commercial ice machine descaling solution following the manufacturer's instructions.
- Alternatively, a solution of white vinegar and water (1 part vinegar to 3 parts water) can be used for light descaling.
- Run the descaling solution through the machine as if making ice (without consuming the ice), then rinse thoroughly by running several cycles with clean water. Discard all ice produced during descaling and rinsing.
6.4 Depo alontèm
- If storing the machine for an extended period, perform a thorough cleaning and descaling.
- Drain all water from the reservoir and ensure all internal components are completely dry to prevent mold or mildew growth.
- Store the machine in a clean, dry, and well-ventilated area.
NAN. Depanaj
This section provides solutions to common issues you might encounter with your ice machine. If the problem persists after attempting these solutions, please contact customer support.
| Pwoblèm | Kòz posib | Solisyon |
|---|---|---|
| Machin pa vire sou. | Pa gen kouran; Interrupteur kouran an etenn; Disjonktè a sote. | Check power cord connection; Ensure power switch is ON; Reset circuit breaker. |
| No ice production. | No water in reservoir; Water bottle empty or improperly seated; Water inlet blocked; Compressor issue. | Refill water bottle and ensure proper seating; Check for blockages; If problem persists, contact support. |
| Ice quality is poor (too wet, too hard, inconsistent). | Incorrect speed setting; Water quality issues; Mineral buildup. | Adjust speed control knob; Use pure water; Perform descaling. |
| Machin nan fè bri. | Cooling fans obstructed; Machine not level; Loose components. | Clear obstructions from fans; Ensure machine is on a level surface; Check for loose parts. |
| Pwodiksyon glas la dousman. | Poor ventilation; High ambient temperature; Mineral buildup. | Ensure adequate clearance around fans; Operate in a cooler environment; Perform descaling. |
8. Garanti ak sipò
YDBMY is committed to providing high-quality products and excellent customer service.
8.1 Enfòmasyon sou Garanti
Specific warranty terms and duration may vary by region and purchase date. Please refer to your purchase documentation or contact your retailer for detailed warranty information.
Generally, the warranty covers defects in materials and workmanship under normal use. It does not cover damage resulting from misuse, neglect, unauthorized modifications, or improper installation.
8.2 Sipò pou Kliyan
If you have any questions about the product, require technical assistance, or need to report an issue, please contact us directly via email. Our customer service team is dedicated to serving you wholeheartedly and ensuring a positive purchasineksperyans g.
Please have your product model (B0F6JJ9PSP) and purchase date ready when contacting support.
