Hiwill WoNoble A502 5.2.2 Dolby Atmos Soundbar User Manual

1. Entwodiksyon

Thank you for choosing the Hiwill WoNoble A502 5.2.2 Dolby Atmos Soundbar. This soundbar features an elegant wooden finish and a 5.2.2 channel system with 9 precision speakers, delivering an immersive Dolby Atmos experience. This manual provides essential information for setting up, operating, and maintaining your soundbar to ensure optimal performance and enjoyment.

The A502 soundbar leverages the acoustic benefits of wood for superior sound quality. Its density enhances resonance and enriches low-frequency response for deeper, fuller sound. Wood minimizes distortion, preserving audio clarity at high volumes and ensuring refined, balanced performance across mid and high frequencies. Its sound diffusion capabilities create a vast, immersive soundstage, enhancing spatiality and listener engagement.

Image 1.1: The Hiwill WoNoble A502 soundbar in a living room setup, positioned beneath a television on a wooden media console, showcasing konsepsyon elegant li yo.

2. Enfòmasyon sou Sekirite

• Li tout enstriksyon ak anpil atansyon anvan ou itilize.
• Kenbe manyèl sa a pou referans nan lavni.
• Pa ekspoze ba son an nan lapli, imidite, oswa tanperati ekstrèm.
• Asire bon vantilasyon alantou inite a.
• Pa bloke okenn ouvèti vantilasyon.
• Sèvi ak sèlman atachman/akseswa manifakti a espesifye.
• Unplug the soundbar during lightning storms or when unused for long periods.
• Refere tout sèvis yo bay pèsonèl sèvis kalifye.

3. Pake kontni

Tanpri verifye ke tout atik yo enkli nan pakè ou a:

• Hiwill WoNoble A502 Soundbar
• Filè Subwoofer
• Adaptè pouvwa
• Kab Stereo 3.5mm
• HDMI ARC kab
• Kab optik
• Kontwòl Remote
• 2 x AAA pil
• Mi twous aliye
• Manyèl itilizatè

4. Pwodwi souview ak Karakteristik

The Hiwill WoNoble A502 soundbar is designed to deliver a premium audio experience with its advanced features:

• 5.2.2 Channel System: Equipped with 9 precision speakers, including two upward-firing speakers for immersive Dolby Atmos.
• Wooden Enclosure: Utilizes the acoustic benefits of wood for enhanced resonance, deeper bass, and minimized distortion, ensuring superior sound clarity.
• Pure Sound Components: Features magnesium-aluminum diaphragms, neodymium magnets, and copper rings for lightweight durability, minimal distortion, and optimized dynamic range, resulting in crisp and detailed high frequencies.
• Sipò Dolby Atmos: Provides an immersive three-dimensional sound experience with precise, object-based sound localization. (Note: DTS decoding is not supported.)
• Resonance Optimization Architecture: Exclusive technology that optimizes the resonance properties of each speaker and the wooden enclosure for perfect sound wave alignment.
• HarmonicX Sound Processing: Enhances vocal clarity through audio output analysis, delivering realistic and precise sound via the integrated 2x3-inch central speaker.
• Integrated Dual Subwoofers: Two 2.5-inch integrated subwoofers provide improved low-frequency balance and overall sound field uniformity, reducing distortion and enhancing audio detail.

Imaj 4.1: Eksploze view of the soundbar, detailing the placement of its 9 speakers, including upward-firing, side, full-range, and integrated subwoofers, for a powerful 5.2.2 channel audio experience.

Image 4.2: Illustration of the soundbar's wooden construction, highlighting the excellent acoustic properties and stability that contribute to superior sound quality.

Image 4.3: Visual representation of the three-dimensional spatial audio experience provided by Dolby Atmos, showing sound waves enveloping a living room.

Imaj 4.4: Yon gwo plan view of the soundbar's upward-firing speaker, demonstrating its capability for precise vertical sound effects, crucial for Dolby Atmos immersion.

Image 4.5: Diagram illustrating how the soundbar enhances the global horizontal sound effect, creating a wider and more immersive soundstage across the room.

5. Enstalasyon

5.1 Plasman

• Plasman Tabletop: Place the soundbar on a stable, flat surface directly in front of your TV. Ensure there are no obstructions in front of the upward-firing speakers.
• Montaj mi: Use the provided wall mounting kit to securely attach the soundbar to the wall below your TV. Follow the instructions in the wall mounting guide for proper installation.

5.2 Koneksyon Inisyal

1. Connect the wired subwoofer to the soundbar using the dedicated subwoofer cable.
2. Connect the power adapter to the soundbar's DC input and then plug it into a power outlet.
3. Choose your preferred audio connection method (HDMI ARC, Optical, or AUX) and connect the soundbar to your TV or other audio source.
4. Mete 2 pil AAA yo nan kontwòl remote la.
5. Press the power button on the soundbar or remote control to turn on the unit.

6. Koneksyon

The Hiwill WoNoble A502 soundbar offers multiple connectivity options:

• HDMI eARC: For the best audio quality and control, connect an HDMI eARC cable from the soundbar's HDMI OUT (eARC) port to your TV's HDMI IN (eARC/ARC) port. This allows for high-resolution audio transmission and TV remote control integration.
• Optik: Connect an optical cable from the soundbar's OPTICAL IN port to your TV's optical audio output.
• AUX: Use the 3.5mm stereo cable to connect the soundbar's AUX IN port to the audio output of devices like smartphones, tablets, or MP3 players.
• Bluetooth 5.3: For wireless audio streaming, pair your Bluetooth-enabled device with the soundbar. Select 'Bluetooth' input on the soundbar and search for 'Hiwill A502' on your device.

Image 6.1: Rear panel of the Hiwill WoNoble A502 soundbar, illustrating the available connection ports including HDMI eARC, Optical, AUX, and the power input.

7. Operasyon Enstriksyon

7.1 Power On/Off

Peze a Pouvwa bouton sou kontwòl remote la oswa sou ba son an pou limen oswa etenn aparèy la.

7.2 Seleksyon Antre

Peze a Antre button on the remote control to cycle through available input sources: HDMI eARC, Optical, AUX, and Bluetooth.

7.3 Kontwòl Volim

Sèvi ak la Volim + epi Volim - buttons on the remote control to adjust the master volume. Press the bèbè button to temporarily silence the sound.

7.4 Mòd son

Your soundbar may feature various sound modes (e.g., Movie, Music, News, 3D). Refer to the remote control for specific buttons to switch between these modes for an optimized listening experience.

8. Mizajou Firmware

To ensure full functionality and access to the latest features, a firmware update may be required. Please note that the memory function is not supported in some initial batches and requires a firmware update.

8.1 Kijan pou Mizajou Firmware

1. Contact Hiwill customer support to obtain the latest firmware file.
2. Telechaje firmwèr la file to a USB flash drive (ensure the file is placed directly on the root directory, not in a folder).
3. With the soundbar powered off, insert the USB flash drive into the soundbar's USB port (if available, otherwise follow specific instructions from support).
4. Follow the on-screen instructions or specific steps provided by Hiwill support to initiate and complete the update process.
5. Do not power off the soundbar or remove the USB drive during the update.

Image 8.1: Firmware Upgrade graphic, highlighting improvements such as expanded surround soundstage, clearer dialogues, deeper bass, reduced default volume, automatic LED turn-off, and softened screen brightness.

9. Antretyen

9.1 Netwayaj

• Toujou debranche ba son an nan priz kouran an anvan ou netwaye li.
• Sèvi ak yon twal mou epi sèk pou siye sifas ekstèn yo.
• Do not use liquid cleaners, aerosols, or abrasive cleaning agents, as they may damage the finish.

9.2 Depo

If storing the soundbar for an extended period, unplug it from the power source and store it in a cool, dry place, preferably in its original packaging to protect it from dust and damage.

NAN. Depanaj

Si ou rankontre pwoblèm ak soundbar ou a, gade pwoblèm ak solisyon komen sa yo:

If the problem persists, please contact Hiwill customer support for assistance.

11. Espesifikasyon

12. Garanti ak sipò

12.1 Garanti manifakti a

The Hiwill WoNoble A502 Soundbar comes with a Garanti manifakti 2 zanGaranti sa a kouvri domaj nan materyèl ak nan fabrikasyon anba itilizasyon nòmal. Tanpri konsève prèv acha ou pou reklamasyon garanti.

12.2 Sipò pou Kliyan

For technical assistance, warranty claims, or any questions regarding your Hiwill WoNoble A502 Soundbar, please contact Hiwill Technologies Inc. customer support. Refer to the contact information provided with your product or visit the official Hiwill websit pou detay sipò.
