Pwodwi souview
The WOLTU 150cm Adjustable Bed Rail is designed to provide safety and comfort for children transitioning from a crib to a bed. It features flexible height adjustment, a double safety lock system, breathable and skin-friendly materials, and convenient one-handed operation for easy access.
- Ajisteman Wotè fleksib: Easily adapts to children's and parents' beds without tools, adjustable from 69-87 cm as the child grows.
- Pwoteksyon Sekirite Doub: Features a double locking system at the top to prevent accidental opening and an L-shaped metal structure for stability. The edge is covered with thick sponge to reduce collision risk.
- Breathable and Skin-Friendly Material: Made from 300D Oxford fabric combined with breathable polyester mesh. The mesh design ensures air circulation and allows parents to observe the child.
- Convenient One-Handed Operation: The one-sided lowering function allows quick lowering of the bed rail with a single hand, facilitating interaction with the child without frequent bending or disassembly.
- Integrated Storage Design: Equipped with a storage bag on the side for bottles, diapers, picture books, and other accessories, keeping the bed area tidy and items within reach.
Enfòmasyon sou Sekirite
Please read all instructions carefully before assembly and use. Keep this manual for future reference. Ensure all components are securely fastened before each use. This product is intended to prevent accidental falls from the bed and is not a substitute for adult supervision.
- Always ensure the bed rail is properly installed and secured according to the instructions.
- Regularly check all parts for wear and tear. Discontinue use if any part is damaged.
- Do not use the bed rail on bunk beds, waterbeds, or beds with inflatable mattresses.
- Ensure there is no gap between the bed rail and the mattress that could trap a child.
- The bed rail is suitable for mattresses with a thickness of 5-30 cm.
Kontni pake
Before assembly, please verify that all parts are present and undamaged. Refer to the diagram below for a list of accessories.
Image: List of accessories for the bed rail, as shown in the installation video.
Enstalasyon ak Enstalasyon
Follow these steps to correctly assemble and install your WOLTU bed rail.
1. Rasanble ankadreman an
- Connect the lower connecting tubes and lift rods. Secure them with the provided screws. Repeat for the other side.
- Install the upper connecting tube and the fence net cover. Slide the net cover onto the upper tubes and secure them to the lift rods.
Image: Step-by-step installation of the lower connecting tube and lift rod, as seen in the installation video.
Image: Attaching the upper connecting tube and fitting the fence net cover, as seen in the installation video.
2. Attach to Bed
- Screw the base of the bed rail to the bedplate. Ensure a secure fit.
- Place the bed rail under the mattress. The L-shaped metal structure should be positioned firmly against the mattress.
Image: Securing the bed rail base to the bed frame using screws, as seen in the installation video.
Image: The bed rail securely installed between the mattress and bed frame, showing minimal connection gaps and material details.
3. Adjust Height and Compatibility
- The bed rail offers 18 levels of height adjustment (69-87 cm) to suit different bed heights and mattress thicknesses (5-30 cm). Adjust the lower tube to align with the height of the person sitting on the mattress, ensuring the lower tube adheres firmly to the mattress.
- This bed rail is compatible with solid wood slatted beds. It is not compatible with beds without slats, metal slatted beds, or spring mattresses.
Imaj: Detaye view of the height adjustment mechanism, showing the range of 69-87 cm and mattress compatibility.
Image: Visual guide to compatible (solid wood slatted beds) and incompatible bed types.
Gid videyo enstalasyon
Video: Installation tutorial for a similar children's bed rail, demonstrating assembly and attachment to the bed.
Enstriksyon Operasyon
Adjusting the Bed Rail Height
The bed rail features 18 levels of height adjustment. To adjust, locate the adjustment buttons on the side supports. Press the buttons and slide the rail up or down to the desired height. Ensure both sides are adjusted evenly and securely locked into place.
Image: Demonstrating the multi-position adjustment feature for changing sheets or accessing the child.
Lowering the Bed Rail
For easy access to your child or to make the bed, the bed rail can be lowered with one hand. Locate the release mechanism on the side. Press the button and gently push the rail downwards until it rests flat against the bed frame. To raise it, simply lift until it clicks into the upright position.
Image: The bed rail in a lowered position, allowing easy access to the bed.
Using the Storage Bag
The integrated storage bag is located on the side of the bed rail. Use it to store small items such as bottles, pacifiers, diapers, or books for convenient access.
Image: Close-up of the integrated storage bag on the bed rail, holding a book.
Antretyen
- Cleaning the Fabric Cover: The fabric cover is machine washable. Remove the cover from the frame before washing. Use a gentle cycle with cold water and mild detergent. Air dry or tumble dry on low heat. Do not bleach or iron.
- Netwaye ankadreman an: Siye pati metal ak plastik ankadreman an ak yon pwodui piblisite.amp twal ak savon dou. Siye byen.
- Enspeksyon regilye: Periodically check all screws, connections, and moving parts to ensure they are secure and functioning correctly. Tighten any loose screws.
- Depo: If storing the bed rail for an extended period, ensure it is clean and dry. Store in a cool, dry place away from direct sunlight.
Image: The bed rail's fabric cover being machine washed for easy cleaning.
Depanaj
| Pwoblèm | Kòz posib | Solisyon |
|---|---|---|
| Balistrad kabann lan pa estab oswa li pa tranble. | Screws are loose; not properly secured to the bedplate; incompatible bed type. | Ensure all screws are tightened. Verify the base is securely attached to the bedplate. Confirm your bed type is compatible (solid wood slats). |
| Bed rail does not lower or raise smoothly. | Mechanism is jammed; dirt or debris in the sliding parts; buttons not fully pressed. | Check for any obstructions. Clean the sliding parts. Ensure adjustment buttons are fully engaged when operating. |
| Gap between bed rail and mattress. | Incorrect height adjustment; mattress too thin or too thick; improper installation. | Adjust the bed rail height to fit snugly against the mattress. Ensure mattress thickness is within 5-30 cm. Re-install the bed rail, ensuring the L-shaped metal structure is firm against the mattress. |
Espesifikasyon
- Mak: WOLTU
- Modèl: 150cm Adjustable Bed Rail
- Koulè: Gri nwa
- Dimansyon: 150 cm (Length) x 87 cm (Max Height)
- Ranje wotè reglabl: 69-87 cm (18 levels)
- Compatible Mattress Thickness: 5-30 cm
- Materyèl: 300D Oxford Fabric, Polyester Mesh, Metal Frame, Thick Sponge Padding
- Pwa: 3.5 kg
- Karakteristik: Double lock system, one-handed lowering, integrated storage bag, machine washable cover.
Garanti ak sipò
For warranty information or technical support, please contact WOLTU customer service through the retailer where the product was purchased. Keep your proof of purchase for warranty claims.
For further assistance, visit the official WOLTU store: Magazen WOLTU
