Entwodiksyon
This manual provides detailed instructions for the setup, operation, and maintenance of your VSTARCAM CB70W 3MP Mini Portable Indoor Security Camera. Please read this manual thoroughly before using the product to ensure proper functionality and safety.
Kontni pake
Verifye ke tout atik yo prezan nan pakè ou a:
- VSTARCAM CB70W Security Camera
- USB Chaje Kab
- Mounting Bracket
- Manyèl Itilizatè (dokiman sa a)
Image: The VSTARCAM CB70W camera with its detachable bracket base, illustrating its compact design and key features like wireless connection, remote active wake-up, quick start, 2000mAh battery, HD night vision, human type detection, and 135° wide angle.
Karakteristik pwodwi
- Konsepsyon kontra enfòmèl ant: Small and portable for flexible indoor placement. Dimensions: 1.7 x 1.7 x 2.2 inches.
- Rezolisyon 2K HD: Provides clear 1296p video for detailed monitoring.
- HD Vizyon lannwit: Advanced infrared night vision for clear visibility in darkness up to 5 meters.
- Deteksyon Mouvman IA: Smart detection technology sends instant alerts to your mobile app upon detecting human movement.
- Long lavi batri: Built-in 2000mAh battery offers 30-100 days standby, depending on frequency of camera awakenings.
- De-fason Audio: Built-in high-quality microphone and speaker for convenient communication.
- Depo fleksib: Supports TF card (up to 256GB, not included) and cloud storage options.
- Pataje Aparèy: Pèmèt plizyè itilizatè view the camera feed from different smartphone devices.
- Lantiy gran ang 135°: Ofri yon pakèt domèn view pou yon pwoteksyon konplè.
Image: Illustration of the camera's compact size, measuring approximately 1.7 x 1.5 x 2 inches, shown next to an AirPods case for scale and in various discreet placements like a bookshelf, bag, or pocket.
Image: A visual representation of the 135-degree wide viewing angle, demonstrating how it captures a broader area suitable for monitoring living rooms, baby rooms, offices, or car interiors.
Gid Enstalasyon
Follow these steps to set up your VSTARCAM CB70W camera:
- Chaje kamera a: Before initial use, fully charge the camera using the provided USB cable and a 5V/1A power adapter (not included).
- Mete Kat TF (Si ou vle): If you plan to use local storage, insert a TF card (up to 256GB, not included) into the designated slot.
- Limen kamera a: Locate the power switch on the camera and slide it to the "ON" position.
- Download the O-Kam App: Scan the QR code provided in the physical manual or search for "O-Kam" in your mobile app store (iOS or Android) and download the application.
- Enskri epi konekte: Open the O-Kam app, register a new account, and log in.
- Ajoute Aparèy: In the app, follow the prompts to add a new device. Scan the QR code located on the camera label to connect the camera to your Wi-Fi network. Ensure your phone is connected to a 2.4GHz Wi-Fi network during setup.
Image: A three-step visual guide showing how to turn on the camera, download the O-Kam Pro app by scanning a QR code, and then use the app to scan the camera's QR code for network configuration.
Enstriksyon Operasyon
App Interface and Functions
Once connected, use the O-Kam app to control and monitor your camera:
- Viv View: Access real-time video feed.
- Deteksyon Mouvman: Enable/disable AI human detection and customize detection zones. Receive push notifications for detected movements.
- Vizyon lannwit: Kamera a chanje otomatikman sou vizyon lannwit nan kondisyon ki gen ti limyè.
- De-fason Audio: Tap the intercom icon to speak through the camera or listen to audio from the camera's location.
- Anrejistreman & Ekran: Manually record video or take screenshots from the live view.
- Lektur: View anrejistre footage stored on the TF card or cloud.
- Anviwònman: Adjust video quality (HD/SD), notification preferences, and other camera parameters.
Image: A user interacting with the O-Kam app on a smartphone, showing the live feed with AI human detection triggered and various control options like motion detection, screenshot, record, night vision, activity zone, and person tracking.
Imaj: Yon fann view demonstrating the camera's HD night vision capability, showing a clear black and white image of a sleeping baby in darkness compared to a color image during the day.
Image: A woman using her phone to communicate via the camera, with speech bubbles illustrating a conversation between her and a child, demonstrating the two-way audio function.
Anrejistreman mòd
The camera supports two primary recording modes:
- Mode ekonomize pouvwa: The camera remains in standby and records only when motion is detected, conserving battery life.
- Always-on Mode: Continuous recording, which will consume battery faster or requires constant power supply.
Image: A comparison of two recording modes: Power-saving mode, which records upon motion detection, and Always-on mode, which provides continuous recording, illustrated with app screenshots.
Enstalasyon
The VSTARCAM CB70W is designed for easy installation without wiring or drilling. Use the included detachable bracket base to place it on a flat surface or mount it on a wall or ceiling using its adhesive backing.
Image: The VSTARCAM CB70W camera shown with its bracket, demonstrating various installation options such as placing it on a desk, mounting it inverted on a ceiling, or attaching it to a wall.
Antretyen
- Netwayaj: Use a soft, dry cloth to clean the camera lens and body. Avoid liquid cleaners or abrasive materials.
- Swen batri: For optimal battery life, avoid extreme temperatures. Recharge the camera when the app indicates low battery.
- Mizajou mikrolojisyèl: Regularly check the O-Kam app for available firmware updates to ensure optimal performance and security.
- Jesyon Depo: Tanzantan review ak jere anrejistre footage on your TF card or cloud storage to free up space.
Image: An illustration highlighting the camera's rechargeable 2000mAh lithium battery, detailing its sleep standby current of 5mA and working current of 400-600mA, emphasizing its durability and long-lasting nature.
Depanaj
| Pwoblèm | Solisyon posib |
|---|---|
| Kamera pa konekte ak Wi-Fi | Ensure your Wi-Fi is 2.4GHz. Check Wi-Fi password. Move camera closer to router. Reset camera and try setup again. |
| Move kalite videyo | Check your Wi-Fi signal strength. Ensure the camera lens is clean. Adjust video quality settings in the app to HD if available. |
| Vizyon lannwit pa klè | Ensure there are no obstructions blocking the infrared lights. Clean the lens. |
| Pa gen odyo oswa move kalite odyo | Check microphone and speaker settings in the app. Ensure no physical obstructions are covering the microphone/speaker. |
| Kout lavi batri | Frequent motion detection or continuous recording will drain the battery faster. Use power-saving mode for extended battery life. Ensure the camera is fully charged. |
| Camera voice prompts are annoying | Connect the camera to the app and disable voice prompts in the camera settings. |
Espesifikasyon
| Karakteristik | Detay |
|---|---|
| Modèl | CB70W |
| Rezolisyon | 3MP (1296p) |
| Itilizasyon Andedan kay la / Deyò | Andedan kay la |
| Koneksyon | Wi-Fi (2.4GHz) |
| Sous pouvwa | Corded Electric (via USB), Battery |
| Kapasite batri | 2000mAh |
| Lavi Batri An Sibstiti | 30-100 jou (selon itilizasyon) |
| Vizyon lannwit | HD Infrared, up to 5 meters |
| Viewing Ang | 135° |
| Opsyon Depo | TF Card (up to 256GB, not included), Cloud Storage |
| Odyo | De-fason odyo |
| Deteksyon Mouvman | AI Deteksyon Imèn |
| Dimansyon (L x W x H) | 1.7 x 1.7 x 2.2 pous |
| Pwa atik | 6.7 ons |
| Materyèl | Plastik |
| To Frame | 15 ankadreman pou chak segonn |
Garanti ak sipò
For warranty information or technical support, please refer to the contact details provided on the product packaging or visit the official VSTARCAM websit. Kenbe resi acha ou pou reklamasyon garanti.
