Entwodiksyon
Thank you for choosing the Soobest 14.2" Large Display Digital Wall Clock. This versatile clock features a large LED screen, 8-in-1 color changing display, date, day of week, temperature, and timer functions. It is designed for easy readability and convenient operation with a remote control, making it ideal for various indoor settings including living rooms, bedrooms, offices, and gyms. This manual provides detailed instructions for setup, operation, and maintenance to ensure optimal performance and longevity of your device.
Image: The Soobest 14.2" Large Display Digital Wall Clock, showcasing its vibrant multi-color display and the included remote control.
Kontni pake
Tanpri verifye pake a ak anpil atansyon pou asire w ke tout atik yo prezan epi yo an bon kondisyon.
- 1 x Soobest 14.2" Large Display Digital Wall Clock
- 1 x kontwòl remote
- 1 x Adaptè Kouran (Avèk Fil Elektrik)
- 1 x Button Battery (for memory function, pre-installed)
- Mounting Hardware (Nails)
- Manyèl Itilizatè (dokiman sa a)
Image: An illustration of all items included in the Soobest Digital Wall Clock package, including the clock, remote, power adapter, and manual.
Enstalasyon
Koneksyon pouvwa
- Unpack the clock and all accessories from the box.
- Connect the power adapter cable to the "power in" port on the back of the clock.
- Plug the power adapter into a standard electrical outlet. The clock display will illuminate.
- The pre-installed button battery serves as a memory function, retaining time and alarm settings during power outages. It does not power the display.
Opsyon Montaj
The clock can be mounted on a wall or placed on a tabletop.
- Mi Mount: Use the provided nails and the mounting holes on the back of the clock to secure it to a wall. Ensure the wall can support the clock's weight (approximately 1.34 pounds).
- Tabletop: The clock can stand freely on a flat surface.
Image: Visual representation of the clock's dimensions and power connection, illustrating its suitability for wall mounting or tabletop use.
Enstriksyon Operasyon
Basic Display Information
The large LED display shows the following information at a glance:
- Tan: Large digits for hours and minutes, with smaller seconds display.
- Dat: Month and Day.
- Jou nan semèn: Indicated by illuminated abbreviations (MON, TUE, etc.).
- Tanperati andedan kay la: Displayed in Fahrenheit (°F).
Sèvi ak kontwòl remote la
All settings and functions are easily controlled via the included remote control.
- Asire w ke kontwòl remote la gen yon pil ki fonksyone.
- Point the remote control directly at the clock for optimal response.
Image: The clock displaying both time and timer modes, highlighting the seamless transition between them using the remote control.
Mete tan ak dat
- Peze a SET button on the remote control. The hour digits will flash.
- Sèvi ak la MWEN / DESANN arrows to adjust the hour.
- Peze SET again to move to minutes, then date, month, and year, adjusting each with the MWEN / DESANN flèch.
- Peze SET one last time to confirm all settings.
Color Changing Display
The clock offers 8 RGB color modes: 4 fixed pure colors and 4 dynamic RGB color changes.
- Peze a KOULÈ button on the remote control to cycle through the available color modes.
- Choose the color that best suits your environment or mood.
Imaj: Egzamples of the clock's diverse color display options, from solid colors to dynamic RGB changes.
Timer Function (Count Up/Count Down)
The clock can function as a timer, useful for kitchen, gym, or study activities.
- Peze a MÒD TIMER button on the remote control to switch to timer mode. The display will show "00:00".
- Setting Countdown: Use the number buttons on the remote to input the desired countdown time (e.g., "0500" for 5 minutes). Press KÒMANSE/KANPE pou kòmanse.
- Setting Count Up: Nan mòd revèy, peze KÒMANSE/KANPE without setting a time to begin counting up from "00:00".
- When a countdown finishes, the clock will emit a crisp beep for 60 seconds.
- Peze MÒD TAN to return to clock display.
Image: The clock functioning as a digital timer, demonstrating its utility in a home gym setting.
Auto Daylight Saving Time (DST)
If your region observes Daylight Saving Time, you can enable the auto DST feature.
- Peze a DST button on the remote control to toggle Auto DST ON or OFF.
- When ON, the clock will automatically adjust forward or backward by one hour at the appropriate times of the year.
Image: A visual explanation of the Auto DST function, showing how the clock automatically adjusts for Daylight Saving Time.
Fonksyon Dimmer
The clock features 5 levels of brightness to suit different lighting conditions and preferences.
- Peze a DIMMER button on the remote control to cycle through the 5 brightness levels.
- Adjust the brightness to prevent the display from being too bright, especially in dark rooms or at night.
Time Format Switch (12/24 Hour)
You can switch between 12-hour (AM/PM) and 24-hour (military) time formats.
- Peze a 12/24H button on the remote control to toggle between the two formats.
Antretyen
- Netwayaj: Use a soft, dry cloth to wipe the clock's surface. Do not use abrasive cleaners or solvents, as they may damage the display or casing.
- Pouvwa: Always ensure the clock is connected to a stable power source.
- Ranplasman Batri (Kontwòl Remote): If the remote control becomes unresponsive, replace its battery. Refer to the remote control's markings for the correct battery type.
- Batri memwa: The internal button battery for memory function typically lasts for a long time. If you notice settings are not retained after a power outage, it may need replacement by a qualified technician.
Depanaj
| Pwoblèm | Kòz posib | Solisyon |
|---|---|---|
| Afich revèy la etenn. | Pa gen koneksyon kouran oswa kouran koupetage. | Ensure the power adapter is securely plugged into the clock and a working electrical outlet. Check the power outlet with another device. |
| Remote kontwòl pa travay. | Remote battery is dead or incorrect orientation. Obstruction between remote and clock. | Replace the remote control battery. Ensure there are no obstructions and point the remote directly at the clock. |
| Time/Date/Day is incorrect. | Not set correctly or Auto DST issue. | Follow the "Setting Time and Date" instructions. Verify Auto DST setting is correct for your region. |
| Ekran an twò klere/fèb. | Dimmer setting is not adjusted. | Sèvi ak la DIMMER button on the remote to adjust brightness levels. |
| Lekti tanperati a sanble pa egzak. | Clock placed near heat source/vent or in direct sunlight. | Relocate the clock to an area with stable ambient temperature. Note that minor variations compared to other thermometers are normal. |
Espesifikasyon
- Mak: Soobest
- Modèl: SO800E
- Kalite ekspozisyon: Dijital dirije
- Gwosè ekspozisyon: 14.2 pous (dyagonal)
- Wotè chif: Approximately 3.1 inches (main time digits)
- Dimansyon pwodwi: 13.1 cm (lajè) x 4.1 cm (wotè) x 1.1 cm (pwofondè)
- Sous pouvwa: Corded Electric (AC Adapter included)
- Batri backup: 1 x Lithium Metal battery (included, for memory function only)
- Karakteristik: Time, Date, Day of Week, Indoor Temperature, Timer (Count Up/Down), 8 RGB Color Modes, 5-Level Dimmer, Auto DST, 12/24H Format.
- Kalite montaj: Monte sou miray / Sou tab
- Materyèl: Plastik
- Pwa atik: 1.34 liv
Garanti ak sipò
The Soobest 14.2" Large Display Digital Wall Clock comes with a 6-mwa garanti apati dat acha a, ki kouvri domaj fabrikasyon.
For technical support, warranty claims, or any questions regarding your product, please contact Soobest customer service. Refer to the contact information provided on the product packaging or the official Soobest websit.
Tanpri konsève resi acha ou a kòm prèv acha pou rezon garanti.
