Soobest Digital Wall Clock User Manual

Entwodiksyon

This manual provides detailed instructions for the setup, operation, and maintenance of your Soobest Digital Wall Clock, Model SO801L. Please read this manual thoroughly before using the product to ensure proper function and longevity. This clock features a large LED display, remote control, countdown timer, and adjustable brightness levels, designed for various indoor environments.

Image: Soobest Digital Wall Clock with its remote control, displaying the time 12:30 and seconds 08.

Kontni pake

Verifye ke tout atik ki nan lis anba a yo enkli nan pakè ou a:

• Soobest Digital Wall Clock (Model SO801L)
• Kontwòl Remote
• Adaptè pouvwa
• Mezire règ
• Mounting Nails (2 pcs)
• Manyèl Enstriksyon

Image: A visual representation of the clock and all included accessories: remote, power adapter, measuring ruler, nails, and manual.

Pwodwi souview

The Soobest Digital Wall Clock SO801L is designed for clear visibility and versatile functionality. Key features include:

• Gwo ekspozisyon dirije: 10.2-inch display with bold, 3-inch digits for easy readability.
• Seconds Display: Provides precise time tracking.
• Kontwòl Remote: Convenient adjustment of settings from a distance.
• Countdown/Count-up Timer: Ideal for gym workouts, cooking, and other timed activities.
• Gradatè 5 nivo: Adjustable brightness to suit various lighting conditions and preferences.
• Lè Ete Otomatik (DST): Automatically adjusts for DST changes.
• Mi konsepsyon mòn: Saves space and provides optimal viewang ing.
• AC Powered ak sovgad batri: Ensures time and settings are retained during power outages (2 AAA batteries not included for backup).

Imaj: Yon plis paseview of the clock's main features, including time, date, seconds, timer, dimmer, 12/24 hour format, remote control, and battery backup.

Enstriksyon Enstalasyon

1. Koneksyon pouvwa:
   • Insert 2 AAA batteries (not included) into the battery compartment on the back of the clock. These batteries provide backup for time and settings during a power outage, but do not power the display.
   • Connect the provided power adapter to the DC input port on the back of the clock.
   • Plug the power adapter into a standard electrical outlet. The clock display will illuminate.
2. Montaj mi:
   • Use the included measuring ruler to mark the desired mounting points on your wall.
   • Drill holes at the marked points and insert the provided mounting nails or appropriate wall anchors.
   • Carefully hang the clock onto the installed nails/anchors. Ensure it is securely fastened.
3. Anviwònman Tan Inisyal:
   • Once powered on, use the remote control to set the current time. Refer to the 'Operating Instructions' section for detailed steps on setting time and other functions.

Image: A visual guide showing the two main setup steps: plugging in the power adapter and using the remote control for initial settings.

Enstriksyon Operasyon

1. Mete Tan ak Dat

1. Press the 'SET' button on the remote control. The hour digits will flash.
2. Use the number buttons (0-9) on the remote to enter the current hour.
3. Press 'SET' again. The minute digits will flash. Enter the current minutes.
4. Continue pressing 'SET' to cycle through setting the year, month, and day, entering the correct values each time.
5. Press 'SET' one last time to confirm all settings.

2. 12/24 Hour Format Switch

Press the '12/24HR' button on the remote control to toggle between 12-hour (with AM/PM indicator) and 24-hour (military time) formats.

3. Lè varè (DST)

Press the 'DST' button on the remote control to activate or deactivate the automatic Daylight Saving Time function. When activated, the clock will automatically adjust for spring forward/fall back.

Image: Illustration of the clock's automatic DST feature, showing how it adjusts for spring forward (+1h) and fall back (-1h).

4. Dimmer Function

The clock features 5 levels of brightness. Press the 'DIMMER' button on the remote control repeatedly to cycle through the brightness levels (Level 1 is the dimmest, Level 5 is the brightest) until you find your preferred setting.

Image: A visual representation of the 5 dimmer levels, from dimmest to brightest, controlled by the remote.

5. Countdown/Count-up Timer

1. Setting Countdown: Press the 'TIMER' button on the remote. The display will show '00:00'. Use the number buttons to enter the desired countdown time (e.g., '0500' for 5 minutes). Press 'START/STOP' to begin the countdown.
2. Konte-up: To start a count-up timer, ensure the timer is reset to '00:00' (press 'RESET' if needed), then press 'START/STOP'.
3. Pòz / rezime: During countdown or count-up, press 'START/STOP' to pause, and press again to resume.
4. Reyajiste: Press the 'RESET' button to clear the timer.
5. Alam: When the countdown finishes, the clock will emit a 60-second beep sound.

Image: A person in a gym setting, with the clock displaying a countdown timer (0:04:59), illustrating its use for workouts.

Antretyen

• Netwayaj: Wipe the clock display and body with a soft, dry cloth. Avoid using abrasive cleaners or solvents.
• Ranplasman batri: If the clock loses time or settings after a power outage, replace the 2 AAA backup batteries in the compartment on the back of the clock.
• Kòd pouvwa: Ensure the power cord is not bent, pinched, or damaged.

Depanaj

Espesifikasyon

Garanti ak sipò

Garanti: This Soobest Digital Wall Clock comes with a 1-year warranty from the date of purchase, covering manufacturing defects. Please retain your proof of purchase for warranty claims.

Sipò Kliyan: For any questions, technical assistance, or warranty inquiries, please contact Soobest customer support:

• Imèl: 202-0014@outlook.com

When contacting support, please provide your product model number (SO801L) and a detailed description of the issue.
