Enstriksyon Sekirite Enpòtan
AVÈTISMAN: Pou diminye risk dife, chòk elektrik, blesi moun, oswa domaj lè w ap itilize aparèy la, swiv prekosyon debaz yo, tankou sa ki annapre yo:
- Li tout enstriksyon yo anvan ou sèvi ak aparèy la.
- Asire w ke yon enstalatè kalifye fè bon enstalasyon ak koneksyon atè a.
- Pa sere materyèl ki ka pran dife anndan oswa toupre aparèy la.
- Pa janm sèvi ak aparèy la pou chofe oswa chofe chanm nan.
- Pa kite timoun yo poukont yo toupre aparèy la.
- Toujou sèvi ak gan pou chodyè sèk. Mouye oubyen mouye.amp detantè po sou sifas cho ka lakòz boule nan vapè.
- Do not touch heating elements or interior surfaces of the oven during or immediately after use.
- In case of a grease fire, smother flames with baking soda or a dry chemical extinguisher. Never use water on grease fires.
- Always turn off all controls when cooking is complete.
- Pa repare oswa ranplase nenpòt pati nan aparèy la sof si yo rekòmande espesyalman nan manyèl sa a. Tout lòt sèvis yo ta dwe refere yo bay yon teknisyen ki kalifye.
Pwodwi souview
The Midea Slide-In Gas Range MGS30S4AST combines powerful cooking capabilities with a sleek design. This appliance features a 5-burner cooktop, including an 18,000 BTU burner for rapid heating, and an oven with Air Fry Convection mode. It also offers Wi-Fi connectivity for remote monitoring and an integrated temperature probe for precise cooking.
Figi 1: Devan view of the Midea Slide-In Gas Range MGS30S4AST. This image shows the stainless steel finish, the five-burner cooktop with grates, and the front-mounted glass touch control panel.
Karakteristik kle:
- Powerful 18,000 BTU Burner: Designed for searing, stir-frying, and rapid boiling.
- Air Fry Convection Mode: For crispy, fried foods with less oil.
- Wi-Fi Capability: Monitor cooking progress and receive alerts via a smartphone app.
- Edge-to-Edge Design: Overlaps countertops for a seamless, built-in appearance.
- Tanperati sonde: Measures internal food temperature and can automatically shut off the oven.
- Glass Touch Control Panel: Easy to clean and operate.
Enstalasyon ak Enstalasyon
Proper installation is crucial for the safe and efficient operation of your gas range. It is strongly recommended that installation be performed by a qualified installer or service technician in accordance with local codes and the National Fuel Gas Code ANSI Z223.1/NFPA 54 (latest edition).
Lis Verifikasyon Pre-Enstalasyon:
- Verify that the gas supply line and electrical outlet meet the requirements specified in the installation manual.
- Asire w ke gen ase vantilasyon.
- Confirm that all packaging materials and protective films have been removed from the appliance.
- Check for any shipping damage. Report any damage immediately to your dealer.
Konekte ak Wi-Fi:
- Download the Midea app from your smartphone's app store.
- Kreye yon kont oswa konekte.
- Follow the in-app instructions to add your Midea Slide-In Gas Range. This typically involves putting the range into pairing mode and connecting to your home Wi-Fi network.
- Once connected, you can monitor and control certain functions remotely.
Enstriksyon Operasyon
Operasyon sou Cooktop:
The cooktop features five sealed burners of varying sizes and power levels. Each burner is controlled by a dedicated knob on the front panel.
- Place cookware centrally on the burner grate.
- Push in the desired burner knob and turn it counter-clockwise to the "LITE" position. You will hear a clicking sound as the igniter sparks.
- Once the burner ignites, continue to hold the knob in for a few seconds, then release.
- Adjust the flame size by turning the knob between "HI" and "LO" settings.
- Pou etenn li, vire bouton an nan sans zegwi mont lan nan pozisyon "OFF".
Nòt: The 18,000 BTU burner is ideal for rapid boiling or high-heat searing. Use appropriate cookware for optimal heat distribution.
Oven Operation (Baking, Roasting, Air Fry Convection):
The oven offers multiple cooking modes accessible via the glass touch control panel.
- Press the "Oven" button on the control panel.
- Select your desired cooking mode (e.g., Bake, Roast, Air Fry Convection).
- Enter the desired temperature using the numeric keypad or +/- buttons.
- Press "Start" to begin preheating. The oven will beep when the set temperature is reached.
- Mete manje a andedan fou a.
- To stop cooking, press the "Off" button.
Air Fry Convection Mode: For best results with Air Fry, use a dark, non-stick baking sheet or an air fry basket placed on a rack. Ensure proper air circulation around food.
Itilizasyon Sond Tanperati a:
- Insert the temperature probe into the thickest part of the meat, avoiding bone or fat.
- Plug the probe into the designated jack inside the oven cavity.
- Select the "Probe" function on the control panel and set the desired internal temperature.
- The oven will automatically turn off when the food reaches the set temperature.
Antretyen ak netwayaj
Regular cleaning and maintenance will ensure the longevity and optimal performance of your Midea Gas Range.
Exterior Surfaces (Stainless Steel and Glass Touch Panel):
- Siye ak yon twal mou dampfini ak savon dou ak dlo.
- For stainless steel, use a non-abrasive stainless steel cleaner and polish in the direction of the grain.
- Avoid abrasive cleaners, scouring pads, or harsh chemicals that can scratch surfaces.
Cooktop and Burner Grates:
- Allow grates and burner caps to cool completely before cleaning.
- Remove grates and wash with warm, soapy water. For stubborn stains, soak them or use a non-abrasive scrub brush.
- Wipe spills on the cooktop surface immediately to prevent baking on.
- Ensure burner ports are clear of food debris. Use a small wire or needle if necessary, but do not enlarge the ports.
Enteryè fou:
- For light soils, wipe with a damp twal ak detèjan twò grav.
- For heavier soils, consult your full owner's manual for instructions on using the self-clean cycle, if available, or recommended oven cleaners.
- Remove oven racks before cleaning the interior.
Depanaj
Anvan ou kontakte sèvis kliyan, review pwoblèm komen ak solisyon sa yo:
| Pwoblèm | Kòz posib | Solisyon |
|---|---|---|
| Burner pa limen. | Alimantasyon gaz la koupe; pò brûler yo bouche; ignisyon an mouye. | Check gas valve; clean burner ports; allow igniter to dry. |
| Fou pa chofe. | Power supply issue; incorrect mode/temperature setting. | Check circuit breaker; verify settings on control panel. |
| Inegal pou kwit manje. | Improper rack position; cookware size/type; oven door opened frequently. | Refer to cooking guide for rack positions; use recommended cookware; avoid opening door unnecessarily. |
| Koneksyon Wi-Fi a echwe. | Router too far; incorrect password; network interference. | Move router closer; re-enter password; check for other devices on network. |
For issues not listed here or if solutions do not resolve the problem, please refer to the complete owner's manual or contact Midea customer support.
Espesifikasyon
The following are key specifications for the Midea Slide-In Gas Range Model MGS30S4AST:
- Nimewo Modèl: MGS30S4AST
- Mak: Midea
- Kalite enstalasyon: Slide-An
- Kalite gaz: Gaz
- Kapasite: 6.1 Pye Kib (Fou)
- Kantite brûler: 5
- Kontwòl konsole: Manyen
- Materyèl: Nerjaveèi asye
- Pwa atik: 281 liv
- Dimansyon pake: 50.87 x 33.69 x 30.56 pous
- Efikasite: Enèji efikas
- Etajè: 2
- Kalite tiwa: Boulanjri, Griye
Garanti ak sipò pou kliyan
For detailed warranty information, please refer to the warranty card included with your appliance or visit the official Midea websit la. Kenbe resi acha ou kòm prèv acha pou reklamasyon garanti.
If you require technical assistance, service, or have questions regarding your Midea Slide-In Gas Range, please contact Midea Customer Support. Contact information can typically be found in your full owner's manual or on the Midea websit.
Ou ka vizite tou Magazen Midea sou Amazon pou plis enfòmasyon sou pwodwi a ak resous sipò.
