Falcon 18000 BTU Cold Split Air Conditioner User Manual

1. Entwodiksyon ak Enfòmasyon sou Sekirite

Thank you for choosing the Falcon 18000 BTU Cold Split Air Conditioner. This manual provides essential information for the safe and efficient operation, installation, and maintenance of your unit. Please read it thoroughly before use and keep it for future reference.

1.1 Enstriksyon Sekirite Enpòtan

• Asire w ke ekipman pou pouvwa a koresponn ak egzijans aparèy la (240V).
• Pa eseye enstale oswa repare aparèy la tèt ou. Kontakte pèsonèl sèvis kalifye.
• Kenbe aparèy la lwen materyèl ki ka pran dife ak sous chalè.
• Pa mete objè nan ouvèti oswa sòti lè a.
• Regularly clean the air filters to maintain efficiency and air quality.
• Dekonekte kouran an anvan ou netwaye oswa fè nenpòt antretyen.

2. Pwodwi souview ak Karakteristik

The Falcon 18000 BTU Cold Split Air Conditioner (Model 167131FLG1) is designed to provide efficient and comfortable cooling for your space. It features an advanced compressor for superior cooling capacity and even air distribution.

2.1 Konpozan kle

• Inite Andedan kay la: Monte andedan chanm nan, responsab pou distribisyon lè a.
• Deyò Inite: Monte deyò, li loje konpresè a ak kondansateur a.
• Kontwòl Remote: Pou operasyon pratik nan inite a.
• Filtè lè: Located in the indoor unit for air purification.

2.2 Karakteristik pwodwi

• Konsepsyon modèn: Blends seamlessly with contemporary interiors.
• Kontwòl Tanperati egzak: Maintain your desired room temperature with high accuracy.
• Four-Way Air Swing: Ensures uniform distribution of cool air throughout the room.
• High-Quality Filtration System: Includes air purification, dust, and anti-bacterial filters for healthier air.
• High Humidity Resistance: Designed to operate effectively in humid conditions.
• Fonksyon Dezumidifikatè: Helps reduce excess moisture in the air.
• Ekspozisyon kache: Integrated for a sleek appearance.

Figure 1: Indoor unit of the Falcon 18000 BTU Split Air Conditioner, showing the Falcon logo and 'Ultra' branding.

Figure 2: Outdoor unit of the Falcon 18000 BTU Split Air Conditioner, featuring the Falcon logo and a protective grille.

3. Enstalasyon ak Enstalasyon

Installation of a split air conditioner requires specialized tools and expertise. It is highly recommended that you contact a certified HVAC technician for professional installation to ensure proper functioning and safety.

3.1 Chèk Pre-Enstalasyon

• Verify that the installation location for both indoor and outdoor units is suitable, allowing for proper airflow and drainage.
• Ensure the electrical wiring meets local codes and the unit's power requirements (240V).
• Confirm that the mounting surfaces are strong enough to support the weight of the units.

3.2 Etap Enstalasyon Pwofesyonèl (Plis paseview)

1. Monte inite andedan an byen fèm sou miray la.
2. Install the outdoor unit on a stable surface, ensuring adequate clearance.
3. Connect the refrigerant lines and electrical wiring between the indoor and outdoor units.
4. Perform vacuuming and refrigerant charging.
5. Test the unit for proper operation and check for leaks.

4. Operasyon Enstriksyon

Your Falcon air conditioner can be operated using the included remote control. Familiarize yourself with the remote's functions for optimal use.

4.1 Operasyon debaz

• Limen/Etenyen: Peze bouton pouvwa a sou kontwòl remote la pou limen oswa etenn inite a.
• Ajisteman Tanperati: Use the temperature up/down buttons to set your desired temperature.
• Seleksyon mòd: Press the 'Mode' button to cycle through available modes (e.g., Cool, Fan, Dry).
• Vitès fanatik: Adjust the fan speed using the 'Fan' button.
• Fonksyon balanse: Activate the four-way air swing for even air distribution.

4.2 Mòd Fonksyònman

• Mòd fre: Bay refwadisman pou bese tanperati chanm nan.
• Mòd fanatik: Fè sikilasyon lè san refwadisman.
• Mòd Sèk (Dezumidifikatè): Diminye imidite nan chanm lan.

Figure 3: User adjusting the air conditioner settings with the remote control for comfortable cooling.

5. Antretyen

Regular maintenance ensures the longevity and efficient performance of your air conditioner. Always disconnect power before performing any maintenance.

5.1 Netwayaj Filtè Lè yo

Ou ta dwe netwaye filtè lè yo chak de semèn oswa pi souvan selon itilizasyon an ak kalite lè a.

1. Louvri panèl devan inite andedan kay la.
2. Retire filtè lè yo avèk anpil atansyon.
3. Lave filtè yo ak dlo tyèd ak yon savon dou. Rense yo byen.
4. Kite filtè yo seche nèt nan yon zòn ki gen lonbray anvan ou mete yo tounen.
5. Fèmen panèl devan an.

5.2 Netwayaj jeneral

• Siye deyò inite enteryè a ak yon twal mou, damp twal. Pa sèvi ak pwodui chimik piman bouk oswa pwodui netwayaj abrazif.
• Ensure the outdoor unit's coils are free from debris (leaves, dust). This can be done by gently brushing or rinsing with water.

NAN. Depanaj

Anvan ou kontakte sèvis kliyan, tanpri gade pwoblèm komen sa yo ak solisyon yo.

Si pwoblèm nan pèsiste apre ou fin eseye solisyon sa yo, tanpri kontakte yon teknisyen sèvis kalifye.

7. Spécifications pwodwi

8. Garanti ak sipò

Your Falcon Air Conditioner is covered by a manufacturer's warranty. Please refer to the warranty card included with your purchase for specific terms and conditions, including warranty period and coverage details.

8.1 Sipò pou Kliyan

For technical assistance, service requests, or warranty claims, please contact Falcon customer support. Contact information can typically be found on the product packaging, the official Falcon websit la, oubyen resi acha ou a.

When contacting support, please have your model number (167131FLG1) and purchase date ready.
