Entwodiksyon
This manual provides essential information for the safe and effective operation, maintenance, and troubleshooting of your Carrera 200989 RC Mario Kart Pipe Kart - Mario. This 1:18 scale remote control vehicle features a 2.4 GHz control system and a rechargeable LiFePO4 battery, offering up to 30 minutes of drive time per charge. Please read this manual thoroughly before first use and retain it for future reference.
Image: The Carrera RC Mario Kart Pipe Kart - Mario remote control car.
Enfòmasyon sou Sekirite
AVÈTISMAN: Danje toufe - Ti pyès. Pa pou timoun ki poko gen 3 an.
Always supervise children during operation. Keep fingers, hair, and loose clothing away from moving parts. Do not operate near water or in wet conditions. Avoid operating in crowded areas to prevent collisions. Ensure the vehicle is turned off when not in use or during charging.
Ki sa ki nan bwat la
- RC Car (Mario Kart Pipe Kart - Mario)
- Kontwòl Remote
- Rechargeable LiFePO4 Battery (for car)
- USB Chaje Kab
- 2 pil AAA (pou kontwòl remote la)
Image: The remote control unit for the Carrera RC Mario Kart.
Enstalasyon
- Enstale pil kontwòl remote: Open the battery compartment on the back of the remote control using a small screwdriver. Insert the two AAA batteries, ensuring correct polarity (+/-). Close the compartment and secure the screw.
- Charge Car Battery: The RC car uses a rechargeable LiFePO4 battery. Connect the included USB charging cable to the car's charging port (located on the underside) and to a USB power source (e.g., computer, USB wall adapter). The charging time is approximately 50 minutes for up to 30 minutes of play. The charging indicator light will show the charging status.
- Pouvwa sou: Once the car battery is charged, turn the ON/OFF switch on the underside of the car to the 'ON' position. Turn the ON/OFF switch on the remote control to the 'ON' position. The remote control and car should automatically pair. A red indicator light on the remote will confirm connection.
- Ajisteman volan: If the car does not drive straight, use the micro-adjustment dial located on the underside of the car to fine-tune the steering until it tracks correctly.
Imaj: Anba view of the Carrera RC Mario Kart, highlighting the battery compartment and ON/OFF switch.
Enstriksyon Operasyon
The Carrera RC Mario Kart Pipe Kart - Mario is designed for easy operation with its intuitive remote control.
- Avant/Atè: Use the left joystick on the remote control to move the car forward or backward.
- Volan gòch/dwat: Sèvi ak joystick dwat la pou dirije machin nan agoch oswa adwat.
- Vitès: The car can reach speeds of up to 5.6 MPH (9 KM/H). Adjust your control inputs for desired speed.
- Tèren: This RC car performs well on various indoor surfaces, including hardwood floors and carpet. For optimal performance and battery life, avoid rough terrain or obstacles that may impede movement.
Imaj: Devan view of the Carrera RC Mario Kart, ready for operation.
Antretyen
- Netwayaj: Use a soft, dry cloth to clean the car and remote control. Do not use water or chemical cleaners, as this may damage electronic components.
- Swen batri: Always turn off the car and remote control after use. Recharge the car's LiFePO4 battery as needed. For long-term storage, ensure the battery is partially charged (around 50%) and store in a cool, dry place. Remove AAA batteries from the remote if storing for extended periods.
- Depo: Store the RC car and remote control in a dry environment, away from direct sunlight and extreme temperatures.
Imaj: Bò kote view of the Carrera RC Mario Kart, illustrating its design for easy maintenance access.
Depanaj
| Pwoblèm | Kòz posib | Solisyon |
|---|---|---|
| Machin nan pa reponn a telekòmand lan. | Low battery in car or remote; not paired; car/remote off. | Ensure both car and remote are ON. Recharge car battery. Replace AAA batteries in remote. Re-pair by turning both off and then on again. |
| Machin nan ap kondui kwochi. | Bezwen ajisteman nan tay volan an. | Use the micro-adjustment dial on the underside of the car to correct the steering. |
| Ti tan pou jwe. | Batri a pa chaje nèt; batri a fin vye. | Ensure the car battery is fully charged (approx. 50 minutes). If battery life significantly decreases, it may need replacement. |
| Interference during operation. | Other 2.4 GHz devices nearby. | Move to an area with less interference. Ensure no other RC devices are operating on the same frequency. |
Espesifikasyon
- Nimewo Modèl: 370200989
- Echèl: 1:18
- Frekans kontwòl: 2.4 GHz
- Vitès maksimòm: Up to 5.6 MPH (9 KM/H)
- Batri machin: Rechargeable LiFePO4
- Batri Remote: 2 x AAA (enkli)
- Tan pou chaje: Apeprè 50 minit
- Tan kondwi: Jiska 30 minit
- Dimansyon pwodwi: 12.9 x 9.1 x 7.5 pous
- Pwa atik: 1.94 liv
- Laj rekòmande: 6 ane ak plis
- Peyi orijin: Lachin
Garanti ak sipò
For warranty information or technical support, please refer to the documentation included with your product or visit the official Carrera websit la. Kenbe prèv acha ou a pou nenpòt reklamasyon garanti.
Manifakti: Carrera
