Manyèl Itilizatè Sistèm Kamera Retou Filaire Fookoo 10" 1080P

Pwodwi souview

The Fookoo 10" 1080P Wired Backup Camera System (Model DY101) is designed to enhance driving safety and visibility for large vehicles such as 5th Wheel Trailers, Tractors, RVs, Trucks, Buses, Semi-Trailers, and Box Trucks. This system features a high-definition monitor and a durable, waterproof camera, providing clear views ak kapasite anrejistreman.

Figure 1: Fookoo 10" 1080P Wired Backup Camera System components.

Karakteristik kle

• 10-inch HD Dual Split Screen Monitor: The monitor features a 1920x1080 pixel display, allowing simultaneous viewing from two cameras. Its larger size provides more detailed visibility, especially beneficial for large vehicles.


  Figure 2: The 10-inch HD monitor provides a larger viewing area for enhanced safety.

• High-Quality IP69 Waterproof Camera: Equipped with a CCD sensor and glass lenses, the camera delivers clear, color images. It is designed to withstand extreme temperatures (-4℉ to 198℉) and is IP69 waterproof, ensuring reliable performance in various weather conditions.


  Figure 3: The durable camera is built to perform in harsh environments.
• Circular Recording Function: The monitor includes a recording feature that provides video evidence of incidents, enhancing driving security. It supports 32-128GB SD cards for continuous loop recording.


  Figure 4: The system records video footage for security and evidence.

• Liy pakin: Integrated parking lines assist with safer and faster parking and reversing maneuvers.


  Figure 5: Parking lines assist in precise vehicle positioning.
• Wide Voltage konpatibilite: The system operates on a 9-36V DC power range, making it compatible with a broad range of large vehicles.

Kontni pake

Verifye ke tout atik ki nan lis anba a yo enkli nan pakè ou a:

• 10-pous ki monitè kè bebe
• Aryè-view Kamera (x1)
• Fil elektrik (x1)
• 4-pin Video Cable (x1)
• Installation Kits (screws, mounting hardware)
• Kontwòl Remote
• Fan ki gen fòm Bracket
• U ki gen fòm Support

Figi 6: Tout konpozan ki enkli nan pake pwodwi a.

Enstalasyon ak Enstalasyon

This is a wired system. Follow these steps for proper installation:

1. Teste sistèm lan: Before permanent installation, connect all components temporarily to ensure they function correctly.
2. Koneksyon pouvwa:
   • Konekte a Wouj wire to ACC (Accessory power).
   • Konekte a Jòn wire to positive power.
   • Konekte a Nwa wire to a metal ground point on the vehicle chassis.
3. Koneksyon kamera: Connect the 4-pin extension cables from the monitor to the cameras. Ensure the notches in the connectors are aligned to prevent damage to the pins.
4. Fil deklanchè (opsyonèl): If you wish to automatically display parking lines or switch camera views when reversing, connect the green trigger wire to your vehicle's reverse light power.
5. Montaj: Securely mount the monitor on your dashboard using the provided brackets. Install the camera(s) at the desired rear or side locations, ensuring a clear view.

Figure 7: Wiring diagram for system installation.

Trailer Quick Connection/Disconnection

For trailers, you can run extra cables to allow easy disconnection of the camera system when the trailer is not in use, eliminating the need for rewiring each time.

Enstriksyon Operasyon

Kontwòl pou kontwole

The monitor features buttons for navigation and control:

• UP+/DOWN-: Navigate menu options or adjust settings.
• MENI: Ale nan meni prensipal la pou paramèt yo.
• SEL: Chwazi yon opsyon oubyen konfime yon paramèt.
• CH-: Chanje ant kamera views (full screen or dual split screen).
• POUVWA: Limen / fèmen monitè a.

Mòd ekspozisyon

The monitor supports various display configurations:

• Ekran konplè: Displays a single camera view.
• Dual Split Screen: Displays two camera views simultaneously. Press the "CH-" button to cycle through available display modes.

Figure 8: Full and dual split screen display options.

Oryantasyon imaj

The camera image can be adjusted for different orientations:

• Nòmal: Estanda view.
• glas: Horizontally flipped view (common for rear-view).
• Flip: Vertically flipped view.
• Mir-Flip: Both horizontally and vertically flipped.

Figure 9: Image orientation settings.

Fonksyon anrejistreman

The system supports circular recording to an SD card (32GB-128GB, not included). When the SD card is full, older videos will be automatically overwritten. Recorded videos can be played back directly on the monitor or transferred to a computer.

Ajisteman Imaj

Adjust image quality settings via the menu:

• Kontras: Ajiste diferans ki genyen ant zòn klere ak zòn fènwa yo.
• Klate: Control the overall lightness or darkness of the image.
• Saturasyon: Modify the intensity of colors.

Figure 10: Image adjustment options.

Antretyen

To ensure optimal performance and longevity of your Fookoo Backup Camera System, follow these maintenance guidelines:

• Netwayaj Monitè a: Use a soft, dry, lint-free cloth to clean the monitor screen. For stubborn smudges, slightly dampLave twal la avèk dlo oswa yon pwodui netwayaj ki pa danjere pou ekran. Evite materyèl abrazif oswa pwodui chimik ki agresif.
• Netwaye lantiy kamera a: Regularly inspect and clean the camera lens to ensure a clear view. Use a soft cloth and, if necessary, a mild glass cleaner. Remove any dirt, mud, or water spots that may obstruct the view.
• Enspeksyon kab: Periodically check all cables and connections for any signs of wear, fraying, or corrosion. Ensure all connections remain secure to prevent signal loss or power issues.
• Pwoteksyon anviwònman: While the camera is IP69 waterproof and designed for extreme temperatures, prolonged exposure to direct sunlight or extreme cold when not in use can be minimized by parking in shaded areas or using protective covers if available.

Depanaj

If you encounter issues with your Fookoo Backup Camera System, consider the following basic troubleshooting steps:

• Pa gen imaj sou monitè a:
  • Tcheke tout koneksyon kouran yo pou asire yo byen fèm epi yo ap resevwa kouran.
  • Verify that the 4-pin video cables are securely connected between the camera and the monitor, with notches aligned.
  • Asire w ke monitè a limen.
• Imaj ki tranble oswa defòme:
  • Tcheke pou koneksyon kab ki lach.
  • Ensure there is no electromagnetic interference from other vehicle electronics.
  • Netwaye lantiy kamera a.
• Anrejistreman an pa fonksyone:
  • Ensure an SD card (32GB-128GB) is inserted correctly.
  • Check if the SD card is full; the system should automatically overwrite, but a faulty card might prevent this. Try formatting the card or using a different one.
• Parking Lines Not Appearing:
  • Verify that the green trigger wire (if used) is correctly connected to the reverse light power.
  • Tcheke paramèt monitè a pou asire liy pakin yo aktive.

Si etap sa yo pa rezoud pwoblèm nan, tanpri kontakte sèvis kliyan Fookoo pou plis asistans.

Espesifikasyon

Garanti ak sipò

Fookoo provides comprehensive support for its products:

• Replacement Support: An 18-month replacement support is offered for defective products.
• Sèvis apre-lavant: Lifetime after-sales service is available to assist with any product-related inquiries or issues.
• Retounen: A 30-day return policy is in place for eligible purchases.

For assistance, please contact Fookoo customer service. You can also visit the official Fookoo store for more information and support resources: Magazen Ofisyèl Fookoo a
