Speedlink DRIFT O.Z. Racing Wheel for PC

Entwodiksyon

This instruction manual provides essential information for the proper setup, operation, and maintenance of your Speedlink DRIFT O.Z. Racing Wheel for PC. Please read this manual thoroughly before using the product to ensure optimal performance and longevity.

Devan view of the Speedlink DRIFT O.Z. Racing Wheel, highlighting its design and controls. For full functionality, drivers must be downloaded from www.speedlink.com.

Enfòmasyon sou Sekirite

• Keep the device away from moisture, dust, and direct sunlight.
• Pa eseye demonte oswa modifye aparèy la. Sa ap anile garanti a.
• Use only with compatible PC systems as specified.
• Ensure proper ventilation around the device during use.
• Avoid excessive force when operating the wheel or pedals.

Kontni pake

Verifye ke tout konpozan yo prezan nan pake a:

• Speedlink DRIFT O.Z. Racing Wheel
• Pedal Unit (Gas and Brake)
• Kovèti pou chanjman
• Manyèl Enstriksyon (dokiman sa a)

The product box illustrating the main components included: the racing wheel, pedal unit, and gear shifter.

Enstalasyon

1. Koneksyon fizik

1. Konekte kab inite pedal la nan pò ki deziyen pou li a sou volan kous la.
2. Connect the USB cable from the racing wheel to an available USB port on your PC.

Step-by-step diagram illustrating the physical connection of the racing wheel to a PC and the pedal unit to the wheel.

2. Enstalasyon chofè

For full functionality and optimal performance, it is recommended to download and install the latest drivers from the official Speedlink websit.

• Vizite www.speedlink.com.
• Navigate to the support or downloads section and locate the drivers for the DRIFT O.Z. Racing Wheel (Model SL-6695-BKOR-01).
• Swiv enstriksyon ki sou ekran an pou konplete enstalasyon chofè a.

Diagram indicating the necessity of downloading drivers from www.speedlink.com and the default DirectInput mode.

3. Monte volan kous la

The racing wheel features suction cups on its base for stable attachment to a flat surface, such as a desk or table.

• Place the racing wheel on a clean, smooth, and flat surface.
• Press down firmly on the wheel base to engage the suction cups, ensuring maximum stability.

Side view of the racing wheel, illustrating the suction cups on the base designed for stable mounting on a flat surface.

Enstriksyon Operasyon

1. Kontwòl souview

The DRIFT O.Z. Racing Wheel is equipped with various controls for an immersive gaming experience:

• Volan: Provides precise steering input.
• D-Pad: Digital directional pad for menu navigation and specific in-game actions.
• Bouton Aksyon (A, B, X, Y): Standard gaming buttons for various functions.
• Shoulder Buttons (LB, LT, RT, RB): Located on the wheel for additional controls.
• Kovèti pou chanjman: Pou chanjman vitès manyèl nan jwèt ki sipòte yo.
• Shift pedal: Located behind the wheel for quick gear changes.
• Pedal: Separate units for gas (accelerator) and brake.

Devan pre view of the racing wheel, detailing the D-pad, action buttons, and central controls.

2. Mode Switching (DirectInput / XInput)

The racing wheel supports both DirectInput and XInput modes, allowing compatibility with a wide range of PC games. The default mode is DirectInput.

• To switch between DirectInput (analog/digital) and XInput modes, press and hold the MÒD bouton pou apeprè 3 segonn.
• The LED indicator will change to confirm the mode switch.
• After switching modes, it is advisable to check button configurations in the game's controller settings or the driver menu.

Diagram showing how to switch between DirectInput and XInput modes by holding the MODE button for 3 seconds, and the corresponding driver menu checks.

3. Vibrasyon Feedback

The racing wheel features vibration effects to enhance realism during gameplay. This function is automatically active in supported games when the appropriate drivers are installed.

4. Adjustable Steering Sensitivity

The steering sensitivity can be adjusted to suit individual preferences and game requirements. Refer to the driver software or in-game controller settings for specific adjustment options.

Antretyen

• Netwayaj: Use a soft, dry cloth to clean the surfaces of the racing wheel and pedals. Do not use abrasive cleaners or solvents.
• Depo: Sere aparèy la nan yon kote ki fre epi sèk, lwen limyè solèy dirèk ak tanperati ekstrèm lè w pa ap itilize li.
• Swen kab: Evite pliye oswa tòde kab yo twòp pou evite domaj.

Depanaj

Pwoblèm komen ak solisyon:

• Device not recognized by PC:
  • Ensure the USB cable is securely connected to both the racing wheel and the PC.
  • Eseye konekte nan yon pò USB diferan.
  • Verify that the latest drivers are installed from www.speedlink.com.
  • Rekòmanse PC ou.
• Buttons or pedals not responding correctly:
  • Check in-game controller settings to ensure the racing wheel is selected and properly configured.
  • Ensure the pedal unit cable is firmly connected to the racing wheel.
  • Verify the operating mode (DirectInput/XInput) is appropriate for the game.
  • Calibrate the device through your PC's game controller settings (Windows Control Panel > Devices and Printers > Right-click on device > Game controller settings > Properties).
• Pa gen fidbak vibrasyon:
  • Ensure the game supports force feedback or vibration effects.
  • Tcheke paramèt nan jwèt la pou asire w ke vibrasyon an aktive.
  • Confirm that drivers are correctly installed.

If issues persist, please refer to the Speedlink support websit pou plis asistans.

Espesifikasyon

Enfòmasyon sou Garanti

Speedlink products are covered by a limited warranty from the date of purchase. This warranty covers defects in materials and workmanship under normal use. It does not cover damage caused by misuse, accident, unauthorized modification, or improper installation.

For detailed warranty terms and conditions, please visit the official Speedlink websit oswa kontakte sipò kliyan.

Sipò pou Kliyan

If you encounter any issues or have questions regarding your Speedlink DRIFT O.Z. Racing Wheel that are not addressed in this manual, please contact Speedlink customer support:

• Websit: www.speedlink.com/support
• Gade nan website for regional contact information, FAQs, and driver downloads.
