Manyèl Itilizatè Scooter Elektrik TODIMART X5

1. Entwodiksyon

Thank you for choosing the TODIMART X5 Electric Scooter. This manual provides essential information for the safe operation, maintenance, and troubleshooting of your scooter. Please read this manual thoroughly before your first ride to ensure proper use and to maximize your riding experience. Keep this manual for future reference.

2. Enfòmasyon sou Sekirite

Sekirite ou pi enpòtan. Toujou respekte direktiv sekirite sa yo:

• Toujou mete yon kas ak ekipman pwoteksyon apwopriye (pwoteksyon jenou, pwoteksyon koud) lè w ap monte bisiklèt.
• Ensure all local laws and regulations regarding electric scooter use are followed.
• Pa monte bisiklèt nan kondisyon mouye, gwo lapli, oswa nan flak dlo.
• Avoid riding on slippery surfaces, uneven terrain, or steep inclines exceeding 25 degrees.
• The maximum load capacity for the TODIMART X5 is 120 kg (265 lbs). Do not exceed this limit.
• Trotinèt sa a fèt pou granmoun.
• Perform a pre-ride check before each use: verify brake functionality, tire pressure, and ensure all quick releases and fasteners are secure.
• Kenbe yon distans sekirite ak lòt machin, pyeton, ak obstak.
• Pa fè kaskad oswa manèv danjere.
• Charge the scooter only with the provided charger.
• Kenbe men ak pye lwen pati k ap deplase yo.

3. Pwodwi souview

Familiarize yourself with the components of your TODIMART X5 Electric Scooter.

Figi 3.1: An jeneral view of the TODIMART X5 Electric Scooter, showing its design, the accompanying mobile application interface, and its folded state.

Figi 3.2: Detaye view of the handlebar and display, highlighting the speed regulator, fault alarm, battery life indicator, headlight switch, brake lever, bell, throttle, and turn signal switch.

Figure 3.3: The scooter's four-light system, including front headlights and rear lights, designed for enhanced visibility.

Konpozan kle:

• Gidon: Pou direksyon ak kontwòl.
• Ekspozisyon: Shows speed, battery level, and other indicators.
• Levye fren: Activates the rear braking system.
• Acct: Kontwole akselerasyon.
• Bell: Pou siyalizasyon.
• Limyè devan/limyè dèyè: For illumination and visibility.
• Mekanis pliye: Pèmèt pou depo ak transpò kontra enfòmèl ant.
• 10-inch All-Terrain Tires: Provide strong grip and shock absorption.
• Motè: High-performance 48V motor (800W for X5 model).
• Batri: High-capacity 48V 15A lithium battery.

4. Enstalasyon

4.1 Unboxing ak Asanble

1. Retire scooter a ak tout akseswa yo nan anbalaj la avèk prekosyon.
2. Depliye scooter a lè w lage l.asinmekanis pliye a. Asire w ke tij la byen bloke nan pozisyon dwat la.
3. Attach the handlebar to the stem, ensuring all cables are properly connected and not pinched. Tighten all screws firmly.
4. Check that both wheels are securely attached and rotate freely.
5. Verify that the brake lever operates smoothly and effectively.

4.2 Premye chaj

Anvan premye woulib ou a, chaje batri scooter a nèt. Sa ede pwolonje lavi batri a epi asire pèfòmans optimal.

Figure 4.1: Illustration of the scooter's battery compartment, highlighting the 48V 15Ah lithium battery and its estimated range of 50-55 km.

• Jwenn pò a chaje sou scooter la.
• Konekte chargeur a nan pò chaje a, apresa branche chargeur a nan yon priz kouran.
• Limyè endikatè ki sou plato a ap anjeneral vin wouj pandan y ap chaje epi vèt lè li konplètman chaje.
• Tan pou chaje a ka varye, men anjeneral li pran plizyè èdtan pou yon chaj konplè.
• Pa kite scooter a ap chaje san sipèvizyon pou yon bon bout tan.

5. Operasyon Enstriksyon

5.1 Power On/Off

• Pou limen: Peze epi kenbe bouton pouvwa a sou ekran an jiskaske ekran an limen.
• Pou etenn: Peze epi kenbe bouton pouvwa a jiskaske ekran an etenn.

5.2 Monte

• Mete yon pye sou platfòm nan epi pouse ak lòt pye a pou pran momantòm inisyal la.
• Once moving, gently press the throttle to accelerate.
• Use the brake lever to slow down or stop. Apply the brake smoothly to avoid sudden stops.
• Kenbe yon pozisyon ekilibre epi kenbe tou de men ou sou gidon an.

5.3 Kontwòl Aplikasyon Entelijan

The TODIMART X5 features smart app connectivity for enhanced control and monitoring.

• Download the exclusive mobile application (refer to the manual's QR code or app store for download).
• Pair your scooter with the app via Bluetooth.
• Atravè aplikasyon an, ou kapab:
• Ajiste vitès vitès.
• Check real-time battery level.
• Lock/unlock the vehicle (anti-theft mode).
• Perform fault diagnostics.
• Record trip data.

5.4 Folding and Transport

The X5 is designed for easy portability with its one-button folding mechanism.

Figure 5.1: Close-up of the scooter's folding mechanism, illustrating how it collapses for compact storage.

Figure 5.2: A person carrying the TODIMART X5 Electric Scooter in its folded state, demonstrating its portability.

• To fold: Ensure the scooter is powered off. Locate the folding lever/button near the base of the stem. Follow the instructions to release the lock and fold the stem down until it clicks into place.
• To unfold: Release the folding lock and lift the stem until it locks securely in the upright position.
• Once folded, the scooter can be easily carried or stored in a car trunk, on public transport, or in small spaces.

6. Antretyen

Antretyen regilye asire lonjevite ak operasyon an sekirite nan scooter ou a.

6.1 Swen Batri

• Chaje batri a regilyèman, menm si w pa ap itilize li, pou kenbe li an bon eta.
• Evite vide batri a nèt anvan ou rechaje li.
• Sere scooter a nan yon kote ki fre epi sèk, lwen limyè solèy dirèk ak tanperati ekstrèm.
• Pa ekspoze batri a nan dlo oswa dife.

6.2 Antretyen Kawotchou

Figure 6.1: Close-up of the scooter's 10-inch all-terrain pneumatic tire, designed for strong grip and shock absorption.

• Check tire pressure regularly. Proper inflation (refer to tire sidewall for recommended PSI) is crucial for ride quality and battery range.
• Anvan chak woulib, enspekte kawotchou yo pou wè si yo gen usure, twou, oswa domaj.

6.3 Sistèm frenaj

Figure 6.2: Illustration of the scooter's reliable disc braking system, ensuring safe stops.

• Tcheke levye fren an regilyèman pou wè si tansyon an kòrèk epi si li reyaji byen.
• Ensure the disc brake pads are not excessively worn. Replace if necessary.

6.4 Netwayaj

• Siye scooter a ak piblisiteamp twal. Pa sèvi ak jè dlo anba gwo presyon oswa plonje scooter a nan dlo.
• Evite itilize pwodui netwayaj abrazif ki ka domaje fini an.

NAN. Depanaj

Si ou rankontre pwoblèm ak scooter ou a, gade pwoblèm ak solisyon komen sa yo:

For issues not listed here or if solutions do not resolve the problem, please contact TODIMART customer support.

8. Espesifikasyon

Jeneral

• Mak: TODIMART
• Non modèl: X5
• Manifakti: YONGKANG MICROSTEP VEHICLE CO., LTD.
• Koulè: Nwa
• Materyèl prensipal: Aliminyòm
• Karakteristik espesyal: Pliable
• Sèvis: Unisex granmoun
• Eleman ki enkli: Electric scooter, charger, tools, manual

Pèfòmans

• Pouvwa motè: 800W (for X5 model)
• Batri: 48V 15Ah ityòm batri
• Estime Ranje: Up to 40-50 km (25-31 miles)
• Kapasite chaj maksimòm: 120 kg (265 liv)
• Max Climb Angle: Jiska 25 degre

Wou & Fren

• Gwosè wou: 10 pous
• Kalite rou: Pneumatic All-Terrain Tires
• Stil fren: Rear Braking (Disc Brake System)

9. Garanti ak sipò

TODIMART is committed to providing high-quality products and excellent customer service. While specific warranty details are not provided in this manual, please retain your proof of purchase for any warranty claims.

For technical support, warranty inquiries, or replacement parts, please contact TODIMART customer service through the retailer where you purchased the scooter or visit the official TODIMART websit pou enfòmasyon kontak.

Please be prepared to provide your scooter's model number (X5) and ASIN (B0F8VNHWFM) when contacting support.
