EJEAS V6 Bluetooth Intercom Headset User Manual

1. Pwodwi souview

The EJEAS V6 Bluetooth Intercom Headset is designed for clear communication among riders. It supports up to 6 rider connections with real-time intercom for 2 riders, offering a maximum range of 800m (600-800m in environments with interference). This device is suitable for most motorcycle helmets and features Bluetooth 5.1 connectivity, CVC noise reduction, and a large capacity battery.

Image: The EJEAS V6 Bluetooth Intercom unit, showing its compact design and control buttons.

2. Pake kontni

Pake a gen ladan atik sa yo:

• 1 x Bluetooth Motorcycle Intercom Unit
• 1 x Ear Speaker and Microphone Headset
• 1 x USB kab
• 2 x Self-adhesive Headphone Felt Pads
• 1 x tournevis
• 1 x Headphone Clamp and Mounting Screws
• 1 x manyèl itilizatè

Image: All components included in the EJEAS V6 Bluetooth Intercom package, laid out neatly, including the intercom unit, headset, cables, and mounting accessories.

3. Aparèy la ak kontwòl yo

Familiarize yourself with the buttons and ports on your EJEAS V6 intercom unit.

Image: Detailed diagram showing the antenna, power on/off, phone/play, volume controls, and headphone jack on the EJEAS V6 intercom unit. Dimensions of the unit and cables are also shown.

• Antèn: Pou transmisyon siyal.
• Rider E / Power On/Off / Rider A: Multi-function buttons for power and intercom connections.
• Phone / Play: Button for call management and music playback.
• Rider B / Rider C / Rider D: Buttons for connecting to other intercom units.
• Volim +/-: Ajiste volim odyo a.
• Kas ekoutè Jack: Connects the ear speaker and microphone headset.

4. Enstalasyon ak Enstalasyon

4.1. Chaje Aparèy la

Before first use, fully charge the intercom unit. The device features a Type-C interface for charging.

Image: The EJEAS V6 intercom unit connected to a power adapter via a USB-C cable for charging, also showing the Type-C interface for headphones and software upgrades.

The charging cable provided is for charging only and does not support data transmission. For software upgrades, use a Type-C data cable with data transmission functionality.

4.2. Pairing Two V6 Intercoms

Follow these steps to pair two EJEAS V6 intercom units for communication:

1. Pouvwa sou: Short-press the intercom button on both devices to turn them on. The indicator light will flash blue.
2. Antre nan Mode Pè: Long-press the intercom button on both devices until the indicator lights flash red and blue alternately.
3. Chwazi Mèt la: Choose one device as the master. Click the intercom button on the master device to start searching for the other unit.
4. Konplete pè a: When both devices flash blue at the same rate, pairing is complete.
5. Antre nan mòd entèkom: Klike bouton entèkom ki sou aparèy prensipal la pou antre nan mòd entèkom.

4.3. Reconnecting Two V6 Intercoms

To reconnect two V6 intercoms after initial pairing:

1. Aparèy demaraj: Short-press the intercom button on both V6 intercoms to turn them on.
2. Inisye Koneksyon: Click the intercom button on either device (master or slave) to initiate the connection.

5. Operasyon Enstriksyon

5.1. Kominikasyon entèkom

The V6 system supports up to 6 rider connections and real-time intercom for 2 riders. The maximum effective distance is 800 meters.

Image: An illustration depicting six motorcycle riders connected via the EJEAS V6 intercom system, highlighting the 1200m ideal distance.

5.2. Bluetooth Koneksyon

The intercom connects to mobile phones and GPS devices via Bluetooth 5.1. Key functions include:

• Tande mizik
• Receiving voice commands from GPS
• Activating Siri and other mobile assistants
• Automatic call answering within 5 seconds
• Ending calls with a single button
• Refè dènye apèl la

5.3. Rediksyon bri

The V6 features advanced DSP noise reduction technology, which effectively reduces background noise by over 90%. This ensures clear voice quality even at speeds up to 120 km/h.

6. Battery and Durability

The EJEAS V6 intercom is equipped with an 850 mAh large capacity battery.

• Tan Itilizasyon: Jiska 18 èdtan
• Tan sibstiti: Jiska 260 èdtan

The device is IP67 waterproof, making it suitable for various applications and weather conditions.

Image: An illustration highlighting the large battery capacity (850mAh), usage time (18-25 hours), standby time (260 hours), Bluetooth 5.1 chip, IP65 waterproof rating, GPS support, DSP noise reduction, 2-person real-time chat, call function, and music playback.

7. Aplikasyon

The EJEAS V6 Bluetooth headset is versatile and can be used in various scenarios, including:

• Motorcycle riding
• Ski
• Sit konstriksyon
• Referee communication

Image: A collage showing the EJEAS V6 intercom being used for motorcycle riding, skiing, referee communication, and on a construction site.

8. Espesifikasyon

NAN. Depanaj

If you encounter any issues with your EJEAS V6 intercom, please consider the following:

• Pa gen pouvwa: Ensure the device is fully charged. Connect it to a power source using the provided USB-C cable.
• Pwoblèm kouple: Repeat the pairing steps carefully. Ensure both devices are in pairing mode (flashing red and blue) before initiating the search from the master unit.
• Dekoneksyon entèkom: If the intercom disconnects, try re-initiating the connection by pressing the intercom button on either unit. Ensure you are within the effective range (up to 800m).
• Kalite odyo pòv: Check the microphone and speaker placement within your helmet. Ensure the CVC noise reduction is active.
• Bluetooth Connection to Phone: If your phone doesn't connect, ensure Bluetooth is enabled on your phone and the V6 is in pairing mode. Forget the device on your phone and try pairing again.

10. Garanti ak sipò

For warranty information and technical support, please refer to the official EJEAS websit la oubyen kontakte revandè w la. Kenbe resi acha w la pou reklamasyon garanti.
